| Property | Parameter | Description |
|---|---|---|
| Product Name | Galvanized Building Envelope Steel | Hot-dip or electro-galvanized steel panels for building facade and roofing systems |
| Base Material Grade | S250GD / S350GD / DX51D | Structural grade cold-rolled steel substrate compliant with EN 10346 |
| Thickness Range | 0.30 – 3.00 mm | Nominal base metal thickness excluding coating layers |
| Width Range | 600 – 1,500 mm | Standard coil and sheet width for envelope applications |
| Length Range | 1,000 – 12,000 mm | Custom cut-to-length sheets or continuous coil supply |
| Zinc Coating Mass | Z100 – Z275 (100 – 275 g/m²) | Total both-side zinc coating weight per EN 10346; heavier coating for aggressive environments |
| Coating Thickness | 7 – 20 µm per side | Measured by magnetic induction method per ISO 2178 |
| Tensile Strength | 330 – 560 MPa | Yield and ultimate tensile strength vary by grade; tested per EN ISO 6892-1 |
| Yield Strength | 250 – 420 MPa | Minimum guaranteed yield strength for structural envelope panels |
| Elongation | ≥ 18 % | Minimum elongation at fracture ensuring formability for profiling |
| Surface Finish | Regular Spangle / Minimized Spangle / Zero Spangle | Selectable zinc crystal pattern; zero spangle preferred for painted envelope systems |
| Corrosion Resistance | ≥ 500 h (Z275, neutral salt spray) | Salt spray test per ISO 9227; actual service life 25 – 50 years depending on environment |
| Packaging | Coil: inner diameter 508/610 mm; Sheet: wooden pallet + steel strapping | Moisture-proof paper interleaving; coil weight up to 25,000 kg |
| Storage Conditions | Dry warehouse, ≤ 70 % RH, 5 – 40 °C | Avoid direct contact with ground; stack height ≤ 1,500 mm for sheets |
| Shelf Life | 12 months (bare); 24 months (pre-painted) | Under recommended storage conditions without significant white rust formation |
| Application | Roof panels, wall cladding, facade cassettes, purlins, curtain wall framing | Suitable for industrial, commercial, and residential building envelope systems |
| Certification | ISO 9001, CE Marking (EN 1090), ISO 14001 | Third-party certified; mill test certificates (MTC) provided per EN 10204 3.1 |
| MOQ | 5,000 kg per grade/thickness | Mixed coil orders accepted; spot and contract supply available |
| Supply Capacity | 50,000 t/month | Multi-mill sourcing capability; lead time 15 – 30 days ex-works |
Initial coating weight inconsistency — resolved after escalation
Our first order of 30 tons of Z600 galvanized coils at 1.2mm for industrial facility cladding in Texas showed coating weight readings below the specified 85-micron minimum on three coils out of the shipment, based on our in-house XRF testing. We raised this with the supplier immediately. To their credit, they responded within 24 hours, arranged third-party verification, confirmed the discrepancy, and replaced the affected coils within 12 business days at no additional cost. MTCs for replacement material were fully compliant with ASTM A653. The issue was handled professionally. We have since placed a follow-up order and quality has been correct. Cautiously optimistic going forward.
