Lightweight Indoor Fiber Cable For Fast Installation

Anxun optical fiber Co., Ltd.

Verified Custom manufacturer · 7 yrs ·

China

Customizable Rock-bottom price

$215 1-49 kilometers Base price

$206 50-99 kilometers 4.2% off

$201 ≥100 kilometers 6.5% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 kilometers

Shipping total: To be negotiated

Subtotal of goods US$ 215.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Lightweight Indoor Fiber Cable

Property	Parameter	Description
Optical Fiber Product Name	Lightweight Indoor Fiber Cable	Ultra-light, flexible fiber optic cable designed for indoor premises wiring and distribution
Fiber Grade & ITU-T Classification	ITU-T G.657A2 / G.652D	Bend-insensitive single-mode fiber; compatible with standard SMF infrastructure
Core & Cladding Diameter Range	Core: 9 µm / Cladding: 125 ± 1 µm	Standard single-mode geometry ensuring low splice loss and broad compatibility
Attenuation Coefficient at 1310nm	≤ 0.35 dB/km	Measured per IEC 60793-1-40; ensures low signal loss in short-haul indoor links
Attenuation Coefficient at 1550nm	≤ 0.20 dB/km	Optimized for long-wavelength transmission in FTTH and LAN applications
Macrobending Loss Performance	≤ 0.1 dB at R=15 mm (1550nm)	Compliant with ITU-T G.657A2; supports tight routing in conduits and cable trays
Chromatic Dispersion Coefficient	≤ 18 ps/(nm·km) at 1550nm	Meets ITU-T G.652D dispersion specification for standard single-mode fiber
Batch Qualification Rate	≥ 99.5%	Each production batch undergoes 100% optical parameter testing before shipment
Manufacturing Environment Standards	ISO 9001:2015 / ISO 14001:2015	Produced in dust-controlled cleanroom environment with full process traceability
Core Raw Material Source	High-purity SiO₂ preform	Sourced from certified preform suppliers; ensures consistent optical performance
Cable Weight	≤ 25 kg/km	Lightweight construction reduces installation labor and structural load on cable trays
Packaging Specification	Wooden drum / 1000 m, 2000 m per reel	Standard reel lengths available; custom lengths accepted upon request
Storage Conditions	Temperature: -20°C to +60°C; Humidity: ≤ 85% RH	Store in dry, ventilated warehouse away from direct sunlight and corrosive agents
Valid Shelf Life	≥ 20 years (installed); 2 years (stored on reel)	UV-stabilized jacket material ensures long-term performance in indoor environments
Application Scenarios	FTTH drop cable, LAN backbone, data center, riser, plenum wiring	Suitable for horizontal and vertical indoor routing in commercial and residential buildings
Compliance & Certification	IEC 60794-2, RoHS, REACH, UL Listed (riser/plenum)	Meets international safety and environmental standards for indoor cable deployment
Minimum Order Quantity (MOQ)	5 km	Flexible MOQ available for project-based procurement; sample orders negotiable
Monthly Supply Capacity	500,000 km/month	Supported by automated production lines with stable raw material supply chain

Lightweight Indoor Fiber Cable For Fast Installation

Lightweight indoor fiber cable has become an essential backbone solution for modern enterprise networks, commercial buildings, data centers, and FTTH last-mile deployments worldwide. Engineered for rapid, hassle-free installation in confined indoor environments, this slim optical cable dramatically reduces labor time and total project cost without compromising signal integrity. As businesses accelerate digital transformation and demand higher bandwidth connectivity, the adoption of indoor fiber optic cable continues to surge across telecom operators, system integrators, and facility managers. Its compact design, low bend radius, and superior transmission performance make it the preferred choice for horizontal cabling, riser runs, and patch installations in offices, hospitals, hotels, and educational campuses globally.

Lightweight indoor fiber cable supplier

What is Lightweight Indoor Fiber Cable?

Lightweight indoor fiber cable is a compact, low-weight optical fiber cable specifically designed for intra-building signal transmission. Compliant with ITU-T G.652D, G.657A1/A2, and IEC 60794-2 standards, it features a tight-buffered or micro-duct construction with a flame-retardant LSZH (Low Smoke Zero Halogen) jacket. Available in single-mode and multimode variants, this indoor optical cable delivers reliable, high-speed data transmission across short to medium distances within controlled indoor environments.

Lightweight indoor fiber cable manufacturer

Lightweight Indoor Fiber Cable Manufacturing and Production Process

Production takes place in ISO 9001-certified, dust-controlled facilities using precision optical fiber drawing and tight-buffering extrusion processes. Each indoor fiber optic cable undergoes rigorous coating application, aramid yarn strength member integration, and continuous LSZH jacket extrusion. Inline optical attenuation testing, tensile load verification, and flame-retardancy checks are performed at every production stage. Final batches are certified to RoHS, REACH, and UL standards before shipment, ensuring full regulatory compliance for global markets.

Lightweight Indoor Fiber Cable Technical Specifications

Core configurations range from 1 to 144 fibers, with cable outer diameters as low as 2.0 mm for simplex and 4.8 mm for multi-fiber variants. Attenuation is ≤0.36 dB/km at 1310 nm and ≤0.22 dB/km at 1550 nm for single-mode types. Minimum bend radius is 10× cable diameter (dynamic) and 7.5× (static). Operating temperature spans -20°C to +70°C, with a tensile strength of up to 1,000 N. LSZH jacket ensures smoke density ≤60% and zero halogen emission, meeting IEC 61034 and IEC 60754 requirements.

Get a Competitive Quote for Lightweight Indoor Fiber Cable

Partner with us for reliable, cost-efficient supply of lightweight indoor fiber cable backed by certified quality and global logistics. We offer flexible MOQ policies, fast lead times, and dedicated technical support to meet your indoor optical cabling project requirements at any scale.

Lightweight indoor fiber cable wholesale

24/7 expert optical communication engineer support
Full ITU-T, ISO, RoHS compliance guarantee for all batches
Exclusive wholesale discounts for bulk telecom, FTTH and data center orders
Complete technical data sheets and on-site deployment guidance included

Contact us today to get your free quote and full specification sheet within 24 hours!

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Anita R.

United States

2025-02-01

Initial shipment had documentation gap — resolved promptly by supplier

Ordered 25,000 meters of 12-fiber OM4 multimode indoor cable for a university campus upgrade project. The cable itself performed well — attenuation and IEC 60794-2 dimensional specs were within tolerance on all tested reels. However, the initial shipment arrived without the UL certification documentation our procurement team required for the contract. I contacted the technical support team and the correct UL and RoHS certificates were emailed within four hours. The issue was administrative rather than a product quality problem. Supplier was responsive and professional in resolving it. Would order again with documentation requirements confirmed upfront.

Liam O.

United Kingdom

2025-02-22

Solid performance on price-to-spec ratio for enterprise patch runs

We trialed 15,000 meters of 2-fiber simplex G.657A2 cable for enterprise office patch and horizontal cabling installations in London. The 2.0 mm OD made installation in congested cable trays noticeably easier. Attenuation and bend radius specs held up against our internal testing benchmarks. Price per meter at this volume was around 12% lower than our previous UK distributor. Lead time of 28 days was slightly longer than hoped but within acceptable range for our project schedule. Would consider increasing order volume once we confirm performance over a longer deployment period.

Omar F.

UAE

2025-03-16

Good value on 144-fiber cable — minor labeling improvement needed

Purchased 40,000 meters of 144-fiber single-mode indoor cable for a large commercial tower project in Dubai. Optical performance is solid — attenuation at 1550 nm averaged 0.21 dB/km across tested reels, fully ITU-T G.652D compliant. Pricing at bulk volume was competitive versus regional distributors. One minor point: reel footage labeling could be more precise for inventory management purposes. Raised this with the account team and they acknowledged it for future orders. Delivery in 25 days was acceptable. Overall good value for the specification level.

Know your supplier

Anxun optical fiber Co., Ltd.

7 yrs on Sinoali.com

Located in China

Company information More goods

FAQ

Q: What types of indoor fiber optic cables do you supply?

A:We supply indoor tight buffer fiber cables, multi-core distribution cables, breakout cables, simplex/duplex patch cables and FTTH indoor drop cables.

Q: What fire resistance standards do your indoor fiber cables meet?

Q: What fiber modes are available for indoor cables?

Q: Can your indoor fiber cables be used for vertical or horizontal cabling?

Q: Are indoor fiber cables bend-resistant?

Q: What is the difference between indoor and outdoor fiber cables?

Product display

Anxun Optical Fiber Co., Ltd. is a technology-driven enterprise specializing in the research, development, and manufacturing of high-quality optical fiber products and communication solutions. With a strong focus on innovation and precision engineering, the company provides a wide range of products, including fiber optic cables, connectivity components, and customized network solutions for telecommunications, data centers, and industrial applications.

Committed to international standards and strict quality control, Anxun ensures reliable performance and long-term durability in all its products. The company continuously invests in advanced production equipment and technical expertise to meet the evolving demands of global communication infrastructure. Guided by a customer-centric approach, Anxun Optical Fiber Co., Ltd. strives to deliver efficient, cost-effective, and sustainable solutions, building long-term partnerships with clients worldwide.
