| Property | Parameter | Description |
|---|---|---|
| Product Name | Pre Terminated Fiber Assembly for Data Center | Factory-terminated fiber optic cable assemblies with connectors pre-installed and tested |
| Fiber Type / Grade | OS2 (Single-mode), OM3, OM4, OM5 (Multimode) | OS2: ITU-T G.652.D; OM3/OM4: IEC 60793-2-10 Type A1a; OM5: IEC 60793-2-10 Type A1a.4 |
| Standard Compliance | IEC 61754, TIA-568.3-D, IEC 61300, ISO/IEC 11801 | Meets international data center cabling standards for performance and interoperability |
| Connector Type | LC, SC, MPO/MTP, ST, FC | MPO-12, MPO-24 common for high-density; LC duplex for standard links; polarity Type A/B/C available |
| Insertion Loss | ≤0.2 dB (PC/UPC); ≤0.35 dB (APC) | Per IEC 61300-3-4; low insertion loss ensures minimal signal attenuation in data center links |
| Return Loss | ≥50 dB (UPC); ≥60 dB (APC) | Per IEC 61300-3-6; APC connectors recommended for single-mode high-speed applications |
| Tensile Strength (Cable) | ≥100 N (short-term); ≥50 N (long-term) | Per IEC 60794-1-2 Method E1; armored versions available up to 2000 N for plenum/riser routes |
| Operating Temperature | -20°C to +70°C | Storage: -40°C to +85°C; suitable for hot-aisle/cold-aisle data center environments |
| Cable Jacket Material | LSZH, Plenum (OFNP), Riser (OFNR), PVC | LSZH per IEC 60332-1; Plenum rated per NFPA 262 for air-handling spaces |
| Fiber Count | 2F, 4F, 8F, 12F, 24F, 48F, 72F, 96F, 144F | MPO trunk cables support 12F or 24F per connector; custom fiber counts available on request |
| Cable Length | 1 m – 100 m (standard); custom up to 500 m | Pre-measured and labeled for rapid plug-and-play deployment; length tolerance ±0.5% |
| Bend Radius | ≥10× cable OD (dynamic); ≥5× cable OD (static) | Bend-insensitive fiber (BIF) options available per IEC 60793-2-10 A1-BI for tight routing |
| Surface Finish / Polish | UPC, APC, PC | End-face geometry per IEC 61300-3-35; factory-polished and 100% tested before shipment |
| Application | Data Center Interconnect, MDA/HDA/EDA Cabling, 40G/100G/400G Networks, Spine-Leaf Architecture | Supports IEEE 802.3ba (40GbE/100GbE) and IEEE 802.3bs (400GbE) high-speed data center links |
| Certification | UL Listed, CE, RoHS, TIA-568, ISO/IEC 11801 | Third-party tested; each assembly ships with factory test report (IL/RL per connector) |
| Packaging | Individually coiled in ESD-safe bags; dust caps on all connectors; pull-out box or reel | Labeled with fiber type, length, polarity, and connector type for easy identification |
| MOQ | 1 piece (standard stock); 50 pieces (custom OEM) | Bulk pricing available for data center rollout projects; lead time 3–7 days for standard configs |
Initial batch had labeling inconsistency — resolved promptly
Ordered 120 MPO-24 OS2 APC trunk cables for a 400G core switch interconnect project. The optical performance itself was fine — insertion loss below 0.35 dB and APC return loss above 50 dB confirmed by our own OTDR testing. However, roughly 15 assemblies had mismatched length labels versus actual measured lengths, creating confusion during structured cabling documentation. I flagged this immediately, and the support team responded within a few hours, issued corrected labeling documentation, and offered priority processing on our next order. The underlying product quality is not in question, but QC on labeling should match the optical testing rigor.
