Outdoor Distribution Fiber Cable For Network Solutions
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 kilometers
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of Outdoor Distribution Fiber
| Property | Parameter | Description |
|---|---|---|
| Optical Fiber Product Name | Outdoor Distribution Fiber | Multi-tube or central-loose-tube outdoor distribution optical fiber cable designed for external plant deployment |
| Fiber Grade & ITU-T Classification | G.652.D / G.657.A1 | Standard single-mode fiber compliant with ITU-T G.652.D; bend-insensitive variant available per G.657.A1 |
| Core & Cladding Diameter Range | Core: 8.2 ± 0.5 µm; Cladding: 125.0 ± 1.0 µm | Tight dimensional tolerance ensures low splice loss and compatibility with standard connectors |
| Attenuation Coefficient at 1310nm | ≤ 0.34 dB/km | Measured per IEC 60793-1-40; suitable for short-to-medium haul outdoor links |
| Attenuation Coefficient at 1550nm | ≤ 0.20 dB/km | Low attenuation at 1550 nm supports long-distance outdoor transmission with minimal signal loss |
| Macrobending Loss Performance | ≤ 0.10 dB (R=30 mm, 100 turns, 1550 nm) | Compliant with IEC 60793-1-47; G.657.A1 variant achieves ≤ 0.03 dB at R=15 mm |
| Chromatic Dispersion Coefficient | ≤ 18 ps/(nm·km) at 1550 nm | Zero-dispersion wavelength range: 1300–1324 nm; dispersion slope ≤ 0.092 ps/(nm²·km) |
| Batch Qualification Rate | ≥ 99.5% | Each production batch undergoes 100% end-to-end OTDR screening and tensile proof testing |
| Manufacturing Environment Standards | ISO 9001:2015 / ISO 14001:2015 | Produced in dust-controlled cleanroom environment; full traceability from preform to finished cable |
| Core Raw Material Source | High-purity synthetic silica (SiO₂ ≥ 99.99%) | Preform manufactured via MCVD/OVD/PCVD process; hydroxyl (OH⁻) content < 1 ppb |
| Packaging Specification | Wooden drum; standard lengths: 2 km, 4 km, 6 km per reel | Drum dimensions and flange diameter comply with IEC 60794-1-1; custom lengths available on request |
| Storage Conditions | Temperature: -20°C to +60°C; Humidity: 10%–85% RH (non-condensing) | Store indoors on flat surface; avoid direct UV exposure and chemical contact; keep drum upright |
| Valid Shelf Life | 25 years (installed); 2 years (uninstalled, sealed packaging) | Fiber coating integrity guaranteed for 2 years from shipment date under recommended storage conditions |
| Application Scenarios | FTTH/FTTB last-mile, campus backbone, aerial/duct/direct-burial outdoor distribution networks | Suitable for OSP (Outside Plant) environments including urban, suburban, and industrial zones |
| Compliance & Certification | ITU-T G.652.D, IEC 60794-1, RoHS 2011/65/EU, TIA-568.3-D | CE marked; UL listed variants available; REACH compliant; halogen-free jacket option available |
| Minimum Order Quantity (MOQ) | 10 km (≈ 3 reels of 4 km standard length) | Sample orders of 1–2 km accepted for qualification testing; OEM/ODM labeling available above MOQ |
| Monthly Supply Capacity | 500,000 km/month (fiber); 80,000 km/month (finished cable) | Capacity scalable based on fiber count and jacket configuration; lead time 15–30 days after order confirmation |
Outdoor Distribution Fiber Cable For Network Solutions
Outdoor distribution fiber cable stands as a cornerstone technology in modern telecommunications infrastructure, enabling reliable, high-speed data transmission across metropolitan networks, campus environments, and long-haul communication systems. As global demand for broadband connectivity accelerates, outdoor distribution fiber has become indispensable for FTTH deployments, enterprise backbone networks, and municipal broadband projects. Engineered to withstand harsh environmental conditions including UV radiation, moisture ingress, extreme temperature fluctuations, and mechanical stress, this specialized cable category delivers consistent optical performance over decades of service life. Network operators, system integrators, and infrastructure developers worldwide rely on outdoor distribution fiber to bridge the gap between central offices and end-user premises, supporting everything from 5G backhaul to smart city applications. Its versatility across aerial, direct-burial, and conduit installation methods makes it the preferred choice for both greenfield deployments and network upgrade projects requiring scalable, future-proof connectivity solutions.
What is Outdoor Distribution Fiber?
Outdoor distribution fiber refers to a multi-fiber optical cable specifically designed for external plant environments, featuring ruggedized jacketing and protective buffer systems that comply with ITU-T G.652D, G.657A1, and IEC 60794 international standards. Typically housing 2 to 144 individual single-mode or multimode optical fibers within a loose-tube or central-tube construction, these cables incorporate water-blocking gel, aramid yarn strength members, and polyethylene outer jackets to ensure long-term signal integrity in outdoor conditions. They serve as the primary distribution medium connecting feeder cables to subscriber drop points across telecommunications access networks.
Outdoor Distribution Fiber Cable Manufacturing and Production Process
Production of outdoor distribution fiber cable takes place in ISO 9001:2015 certified facilities under strict cleanroom-controlled environments to prevent contamination during fiber handling. The manufacturing sequence begins with precision fiber drawing from high-purity silica preforms, followed by UV-cured acrylate coating application. Individual fibers are then assembled into color-coded loose tubes filled with thixotropic water-blocking gel. Strength members comprising glass-reinforced plastic rods or aramid yarn are applied before automated extrusion of the high-density polyethylene outer sheath. Every production batch undergoes 100% optical attenuation testing, tensile load verification, and crush resistance validation to meet RoHS and REACH compliance requirements.
Outdoor Distribution Fiber Cable Technical Specifications
Standard outdoor distribution fiber cable configurations offer attenuation values of ≤0.35 dB/km at 1310 nm and ≤0.20 dB/km at 1550 nm for single-mode variants compliant with ITU-T G.652D. Cable outer diameters range from 8.0 mm to 22.0 mm depending on fiber count, with operating temperature ranges spanning -40°C to +70°C. Minimum bend radius is maintained at 20× cable diameter under installation load and 10× at no-load conditions. Tensile strength ratings reach 2,700 N for standard grades and 5,400 N for armored configurations. Crush resistance exceeds 3,000 N/100 mm, ensuring structural integrity in direct-burial and conduit applications. Available fiber counts include 4F, 6F, 12F, 24F, 48F, 72F, 96F, and 144F configurations.
Get a Competitive Quote for Outdoor Distribution Fiber
Partner with our team for premium outdoor distribution fiber cable solutions backed by verified quality certifications, flexible MOQ policies, and global logistics support. We offer competitive wholesale pricing for bulk telecom, FTTH rollout, and data center interconnect projects with guaranteed lead times and full documentation packages tailored to your procurement requirements.
- 24/7 expert optical communication engineer support
- Full ITU-T, ISO, RoHS compliance guarantee for all batches
- Exclusive wholesale discounts for bulk telecom, FTTH and data center orders
- Complete technical data sheets and on-site deployment guidance included
Contact us today to get your free quote and full specification sheet within 24 hours!
