Waterproof Color Coated Aluminum Sheet - Mill Direct

Xinpeng Color Coating Co., Ltd.

Verified Custom manufacturer · 2 yrs ·

China

Customizable Rock-bottom price

$3180 1-49 ton Base price

$3040 50-99 ton 4.4% off

$2970 ≥100 ton 6.6% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 ton

Shipping total: To be negotiated

Subtotal of goods US$ 3,180.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Waterproof Color Coated Aluminum Sheet

Property	Parameter	Description
Product Name	Waterproof Color Coated Aluminum Sheet	Pre-painted aluminum sheet with waterproof coating for exterior and interior applications
Material Grade	1100, 3003, 3105, 5052, 5083 (AA Grade)	Equivalent to EN AW-1100, EN AW-3003, EN AW-5052; corrosion-resistant alloy series
Standard Compliance	ASTM B209, EN 485-2, GB/T 3880	Meets international standards for aluminum alloy sheet and strip
Chemical Composition	Al ≥99.0% (1100); Mn 1.0–1.5% (3003); Mg 2.2–2.8%, Cr 0.15–0.35% (5052)	Alloy elements ensure strength, formability, and corrosion resistance
Tensile Strength	110–290 MPa (varies by alloy and temper)	Per ASTM B209; 1100-H14: ≥110 MPa; 5052-H32: ≥230 MPa
Yield Strength	85–215 MPa	1100-H14: ≥95 MPa; 5052-H32: ≥160 MPa; suitable for structural forming
Elongation	4–12%	Measured on 50 mm gauge length per ASTM B209; varies by alloy and temper
Coating Type	PVDF, PE (Polyester), SMP, HDP	PVDF offers superior UV resistance and weatherability; PE suitable for interior use
Coating Thickness	Top coat: 18–25 μm; Primer: 5–7 μm; Back coat: 8–12 μm	Measured per ASTM D7091; ensures waterproof and anti-corrosion performance
Thickness Range	0.2–4.0 mm	Custom thickness available; common sizes: 0.5 mm, 0.8 mm, 1.0 mm, 1.5 mm, 2.0 mm
Width Range	600–2,200 mm	Standard widths: 1,000 mm, 1,220 mm, 1,500 mm; custom slitting available
Length Range	1,000–6,000 mm (sheets); coil form available	Standard sheet lengths or coil supply; coil weight up to 5 MT
Surface Finish	Smooth, Embossed, Brushed, Stucco	Waterproof gloss or matte finish; RAL/Pantone custom color matching available
Application	Roofing, cladding, ACP panels, signage, transportation, decoration	Widely used in construction facades, industrial roofing, and marine environments
Certification	ISO 9001:2015, SGS, CE, RoHS	Quality management and environmental compliance certified
Packaging	Wooden pallet with waterproof film wrapping; edge protectors applied	Export-standard packaging; suitable for sea, air, and land freight
MOQ	1 MT per color/specification	Mixed specifications accepted; sample orders available upon request

Waterproof Color Coated Aluminum Sheet - Mill Direct

Waterproof color coated aluminum sheet serves as one of the most versatile and performance-driven materials in modern construction, industrial packaging, and architectural cladding applications. Engineered with a multi-layer protective coating system applied directly over aluminum substrate, this product delivers outstanding moisture resistance, UV stability, and long-term aesthetic appeal. Unlike conventional painted metals, the specialized waterproof coating forms a seamless barrier that prevents water infiltration even under prolonged exposure to rain, humidity, and extreme weather cycles. Industries ranging from roofing and curtain wall fabrication to transportation panels and household appliance manufacturing rely on this material for its combination of lightweight properties — typically 2.70 g/cm³ density — and exceptional durability. Mill-direct supply ensures tighter dimensional tolerances, consistent coating adhesion, and cost-effective pricing that downstream distributors simply cannot match. Whether your project demands a matte finish, high-gloss surface, or woodgrain texture, waterproof color coated aluminum sheet provides the design flexibility and structural reliability your specifications require.

What is Waterproof Color Coated Aluminum Sheet?

Waterproof color coated aluminum sheet is a pre-finished aluminum product manufactured by applying one or more layers of moisture-resistant organic coatings — including PVDF, polyester (PE), or HDP resin systems — onto a cleaned and chemically treated aluminum alloy base, commonly 1050, 3003, 3105, or 5052 series. The finished product resists water penetration, chemical corrosion, and surface degradation, maintaining color uniformity over service lives exceeding 20 years under standard atmospheric conditions.

Waterproof Color Coated Aluminum Sheet Manufacturing Process

Production begins with continuous coil feeding of aluminum substrate through a multi-stage cleaning and chromate or chrome-free passivation pretreatment line, which enhances coating adhesion strength to a minimum cross-cut rating of Grade 0 per ISO 2409. Primer and topcoat layers are then applied via precision roll-coating heads and cured in high-temperature ovens at 220–260°C, achieving dry film thickness of 18–35 μm for standard polyester grades and 25–40 μm for PVDF systems. Final inspection includes pencil hardness testing (≥2H), T-bend flexibility evaluation, and salt spray resistance verification exceeding 1,000 hours per ASTM B117.

Waterproof Color Coated Aluminum Sheet Technical Specifications

Standard alloy grades include 1100-H14, 3003-H16, and 5052-H18, with tensile strength ranging from 145 MPa to 290 MPa depending on temper selection. Available thickness spans 0.2 mm to 4.0 mm, with coil widths up to 1,600 mm and sheet lengths customized to order. Coating systems comply with ASTM D522, EN 13523, and GB/T 17748 standards. Color options exceed 200 RAL and Pantone references, with 60° gloss values adjustable from 10 GU (matte) to 85 GU (high-gloss). Peel adhesion strength meets or exceeds 4N/mm per EN ISO 4624, ensuring the waterproof coating layer remains intact through forming, bending, and installation processes.

Waterproof color coated aluminum sheet manufacturer

Get a Competitive Quote for Waterproof Color Coated Aluminum Sheet

Partner with our mill-direct team to secure cost-effective pricing, verified quality certifications, and fast lead times on waterproof color coated aluminum sheet for your next project. Our technical specialists are ready to match the exact alloy, temper, coating system, and color specification your application demands.

Waterproof color coated aluminum sheet supplier

24/7 customer support available
Free samples for quality evaluation
Competitive pricing for bulk orders
Professional technical consultation

Contact us today to get your free quote within 24 hours!

Waterproof color coated aluminum sheet wholesale

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Kevin L.

United States

2025-02-01

Initial color batch variance — resolved satisfactorily by the team

First order was 8 tons of 1100-H14, 0.4 mm, polyester coating in a custom RAL 1013. On arrival, our QC team identified a visible color shift between two coils that exceeded our delta-E tolerance of 1.0. We raised the issue immediately. The supplier's technical team responded within 24 hours, acknowledged the variance from their colorimetry records, and arranged a replacement production run at no additional cost, delivered within 15 days. The replacement coils were within delta-E 0.6 across all units. Issue was handled professionally. We have since placed a follow-up order and results were clean. Marking 3 stars for the initial problem, but confidence has been restored.

Claire B.

United Kingdom

2025-02-22

Solid polyester coated product at competitive mill-direct pricing

Ordered 10 tons of 3003-H16 in 0.6 mm polyester coating, matte anthracite RAL 7016, for roofing sheet fabrication. Coating adhesion and flexibility testing per ASTM D522 passed our incoming QC checks without issues. Gloss consistency across coils was acceptable, though we noted slightly wider variation (±3 GU) on two coils compared to the rest of the batch — within tolerance but worth monitoring. Mill-direct pricing offered a meaningful saving over our UK-based stockholder. Technical documentation was complete. Overall a reliable supply source we plan to continue using, particularly for higher-volume runs where the cost advantage is most significant.

Omar K.

UAE

2025-03-16

Good value on PVDF stock for external facade — minor lead time note

Purchased 12 tons of 3105 alloy, 0.8 mm, PVDF coating in RAL 9006 for an external facade contract in Dubai. Coating thickness and salt spray performance (verified at 1,000+ hours, ASTM B117) were fully satisfactory for our Gulf climate requirements. Price per ton was noticeably lower than regional distributors. One point to flag: initial quoted lead time was 20 days but actual delivery ran 26 days due to port congestion — the team communicated proactively about the delay, which we appreciated. Quality itself was not in question. Would order again with slightly more buffer in project scheduling.

Know your supplier

Xinpeng Color Coating Co., Ltd.

2 yrs on Sinoali.com

Located in China

Company information More goods

Company Profile

Xinpeng Color Coating Co., Ltd. is a specialized industrial enterprise focusing on high-performance Color Coated Steel Sheet production and global export business. We integrate independent research, production and trade, supplying standard and custom color coated steel sheets with complete material grades and color options.

Equipped with international-level production equipment and sophisticated testing instruments, we implement full-process quality inspection to guarantee corrosion resistance, surface flatness and coating durability. With abundant spot inventory, professional export packaging and efficient logistics scheduling, we support bulk orders and short lead times. Our products serve construction engineering, automotive industry, household appliances, shipbuilding and energy sectors. We uphold integrity and innovation, commit to tailored solutions and stable supply for worldwide B2B customers.
