| Property | Parameter | Description |
|---|---|---|
| Product Name | Thin Cold Rolled Color Steel Sheet | Pre-painted cold rolled steel sheet with decorative and protective coating |
| Material Grade | SPCC / DC01 / Q195 / Q235 | International equivalents: SPCC (JIS G3141), DC01 (EN 10130), Q195/Q235 (GB/T 708) |
| Standard Compliance | GB/T 12754, EN 10169, ASTM A755/A755M, JIS G3312 | Covers prepainted/color-coated cold rolled steel coil and sheet specifications |
| Chemical Composition (C) | ≤ 0.12% | Low carbon content ensures good formability and paintability |
| Chemical Composition (Mn) | ≤ 0.50% | Manganese content per base material grade requirements |
| Chemical Composition (P / S) | P ≤ 0.045%, S ≤ 0.045% | Controlled phosphorus and sulfur for improved surface quality |
| Tensile Strength | 270–500 MPa | Varies by base metal grade; SPCC/DC01 typically 270–410 MPa (EN 10130 / JIS G3141) |
| Yield Strength | 140–350 MPa | Minimum yield strength depends on substrate grade and temper |
| Elongation | ≥ 28–36% | High elongation ensures excellent bending and forming performance |
| Thickness Range | 0.12–1.20 mm | Thin gauge; common sizes: 0.14 mm, 0.18 mm, 0.25 mm, 0.40 mm, 0.60 mm, 0.80 mm |
| Width Range | 600–1,500 mm | Custom slit widths available; standard coil width 914 mm / 1,000 mm / 1,219 mm |
| Coating Type | Polyester (PE), PVDF, Epoxy, SMP | Top coat 5–25 μm; primer 5–7 μm; back coat 5–15 μm; zinc or galvalume substrate |
| Surface Finish | Smooth, Matte, Embossed, Textured | RAL/custom color available; gloss level 10–80 GU; pencil hardness ≥ 2H |
| Application | Roofing, wall cladding, home appliances, furniture, signage, HVAC ducts | Widely used in construction, electrical enclosures, and interior decoration |
| Certification | ISO 9001, SGS, BV, CE | Mill test certificate (MTC) per EN 10204 3.1 available upon request |
| Packaging | Coil or sheet; waterproof paper + steel strip strapping + wooden pallet | Export seaworthy packaging; coil weight typically 3–8 MT |
| MOQ | 5 MT per order | Mixed specifications accepted; lead time 7–20 days depending on quantity |
Initial color variance issue — resolved after supplier follow-up
First order of 15 tons of 0.4mm polyester-coated sheet in a custom RAL color showed slight gloss variation between two coil lots — measured difference was about 8 GU at 60°, noticeable side by side. Raised the issue immediately; the supplier's technical team responded within 4 hours, reviewed our photos, and confirmed a calibration drift during that production run. They arranged replacement coils within 12 days at no additional cost and provided updated QC documentation. Subsequent delivery was consistent and within spec. Appreciate the responsive handling — gives us confidence to continue the relationship cautiously.
