Technical Specifications of Hot Dip Galvanized Color Coating Steel

Property	Parameter	Description
Product Name	Hot Dip Galvanized Color Coating Steel	Prepainted galvanized steel sheet/coil with hot-dip zinc base coating
Material Grade	DX51D+Z, DX52D+Z, SGCC, CS-B	Equivalent to EN 10346, JIS G3302, ASTM A653; base metal low carbon steel
Standard Compliance	ASTM A755M, EN 10169, JIS G3312, GB/T 12754	International standards for prepainted hot-dip galvanized steel products
Chemical Composition (Base)	C ≤0.12%, Mn ≤0.60%, P ≤0.045%, S ≤0.045%, Si ≤0.50%	Low carbon steel substrate ensuring good formability and coating adhesion
Zinc Coating Mass	Z60–Z275 (g/m²); AZ50–AZ150 for Galvalume	Double-side coating per ASTM A653; higher coating weight improves corrosion resistance
Paint Coating Type	Polyester (PE), PVDF, SMP, HDP, Epoxy	Top coat 15–25 µm; primer 5–7 µm; back coat 5–12 µm; PVDF for superior weather resistance
Tensile Strength	270–500 MPa (per EN 10346 / ASTM A653)	DX51D+Z: ≥270 MPa; DX52D+Z: ≥270 MPa; varies by grade and temper
Yield Strength	140–420 MPa	DX51D+Z: 140–300 MPa; DX52D+Z: 140–300 MPa; suitable for roll forming and bending
Elongation	≥22% (A80mm, per EN 10346)	Good ductility for profiling, roofing, and cladding applications
Thickness Range	0.14–1.50 mm (base metal)	Total thickness including zinc and paint layers; standard tolerance ±0.02 mm
Width Range	600–1,500 mm	Slit coil or full-width coil available; custom widths upon request
Coil Inner Diameter	508 mm / 610 mm	Standard ID for coil; coil weight 3–8 MT per coil
Surface Finish	Smooth, Embossed, Matte, High Gloss	RAL color system available; 60° gloss value 10–85 GU; UV-resistant top coat
Application	Roofing, wall cladding, home appliances, garage doors, HVAC ducts, automotive parts	Widely used in construction, household appliances, and industrial sectors
Certification	ISO 9001, CE, SGS, RoHS	Mill test certificate (MTC) per EN 10204 3.1 available upon request
Packaging	Eye-to-sky or eye-to-wall coil; waterproof paper + steel strip strapping	Seaworthy export packaging; moisture-proof inner wrapping for ocean freight
MOQ	25 MT per order	Mixed specifications accepted; sample order negotiable for new customers

Hot Dip Galvanized Color Coating - Mill Direct Supplier

Hot Dip Galvanized Color Coating steel is one of the most versatile and high-performance surface-treated materials available in today's construction and manufacturing markets. Combining the robust corrosion protection of hot-dip galvanization with the aesthetic versatility of polymer-based color coatings, this product serves critical roles in roofing systems, wall cladding, home appliances, automotive components, and industrial enclosures. As a mill-direct supplier, we deliver premium-grade coated steel that meets the most demanding international quality standards, including ASTM A755, EN 10169, and JIS G3312. Our hot dip galvanized color coating products are engineered to withstand harsh environmental conditions while maintaining long-term visual appeal, making them the preferred choice for architects, contractors, and OEM manufacturers seeking both durability and design flexibility at cost-effective mill-direct rates.

Hot Dip Galvanized Color Coating supplier

What is Hot Dip Galvanized Color Coating?

Hot Dip Galvanized Color Coating — commonly referred to as HDGCC or prepainted galvanized steel — is a multi-layer steel product in which a base steel substrate undergoes hot-dip galvanization to achieve a zinc coating weight typically ranging from Z60 to Z275 g/m², followed by chemical passivation, primer application, and a topcoat of polyester, PVDF, or HDP paint. The final product delivers outstanding anti-corrosion properties combined with a durable, UV-resistant decorative surface finish.

Hot Dip Galvanized Color Coating Manufacturing Process

Production begins with cold-rolled steel coils fed through a continuous hot-dip galvanizing line, where the substrate is immersed in a molten zinc bath maintained at approximately 450°C to achieve a uniform zinc-iron alloy bond. The galvanized strip then undergoes surface passivation and chromate or chromate-free treatment before entering the color coating line. A primer coat of 5–8 µm is applied, cured at 220°C, followed by a topcoat of 15–25 µm baked at temperatures between 230°C and 260°C, ensuring optimal adhesion and film hardness of 2H minimum per ASTM D3363.

Hot Dip Galvanized Color Coating Technical Specifications

Our hot dip galvanized color coating products are available in the following standard technical parameters to meet diverse project requirements:

Base Material: Cold-rolled steel, yield strength 250–550 MPa per ASTM A653
Thickness: 0.12 mm – 1.50 mm (±0.02 mm tolerance)
Width: 600 mm – 1,500 mm (custom slit widths available)
Zinc Coating Weight: Z60 – Z275 g/m² (double-sided, per ASTM A90)
Topcoat Thickness: 15 µm – 25 µm (polyester, PVDF, or HDP)
Pencil Hardness: ≥ 2H (ASTM D3363)
T-Bend Test: 0T – 2T without cracking (ASTM D4145)
Salt Spray Resistance: ≥ 500 hours (ASTM B117)
Color Options: RAL standard palette and custom colors available
Coil Weight: 3 – 10 MT per coil

Get a Competitive Quote for Hot Dip Galvanized Color Coating

Partner with our mill-direct team to access superior-quality hot dip galvanized color coating at highly competitive pricing. We support projects of all scales — from small custom orders to large-volume procurement — backed by rigorous quality inspection and fast global shipping lead times of 15–25 days.

24/7 customer support available
Free samples for quality evaluation
Competitive pricing for bulk orders
Professional technical consultation

Contact us today to get your free quote within 24 hours!

Hot Dip Galvanized Color Coating manufacturer

Hot Dip Galvanized Color Coating wholesale

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Liam O.

Australia

2025-02-01

Initial Width Tolerance Issue — Resolved Quickly by Supplier

Our first order of 25 MT of 1,200 mm wide HDGCC coils for roofing sheet production arrived with three coils measuring 1,195–1,197 mm, slightly outside our agreed ±2 mm tolerance. I raised the issue with the sales team and they responded within hours, issued a credit note for the affected coils, and confirmed a process adjustment for subsequent orders. Our second shipment of 30 MT was fully within spec. The core product quality — Z120 zinc, 18 µm polyester topcoat, ASTM B117 salt spray compliance — is good. Communication after the issue was handled professionally.

Klaus M.

Germany

2025-02-22

Competitive Pricing on EN 10169 Material — Would Benefit from More Color Stock

We sourced 0.60 mm prepainted galvanized steel to EN 10169 standard for facade cladding on a commercial building project in Cologne. Zinc coating at Z140 and polyester topcoat at 20 µm performed well through our forming and cutting process. Price per MT was competitive versus European service centers. We rate 4 stars because two of our requested RAL colors required custom production with a 5-day lead extension, which is understandable but worth noting for buyers with tight schedules. Technical documentation package was thorough.

David H.

United States

2025-03-16

Good Value on Thin-Gauge Material — Minor Lead Time Variance

We purchase 0.18 mm and 0.22 mm HDGCC in Z60 coating weight for home appliance inner panels. Material quality is solid — pencil hardness and T-bend results consistently meet our internal spec derived from ASTM D3363 and D4145. Pricing at mill-direct rates is noticeably better than our previous distributor, roughly 8–10% lower on comparable specs. Only reason for 4 stars: one shipment arrived 4 days past the quoted 20-day window due to port congestion. The team communicated proactively and the delay didn't affect our production run.
