| Property | Parameter | Description |
|---|---|---|
| Product Name | Metal Building Color Steel Sheet | Pre-painted galvanized/galvalume steel sheet for building applications |
| Material Grade | DX51D, S280GD, S350GD / SGCC, SGCH | International equivalents: DX51D+Z (EN), SGCC (JIS), Q235 (GB) |
| Standard Compliance | EN 10346, ASTM A755, JIS G3312, GB/T 12754 | Meets international pre-painted steel coil and sheet standards |
| Base Metal Coating | Galvanized (GI) / Galvalume (GL) | Zinc coating: Z60–Z275 g/m²; Al-Zn coating: AZ50–AZ150 g/m² |
| Chemical Composition (C) | ≤ 0.12% | Low carbon content ensures formability and weldability |
| Chemical Composition (Mn) | ≤ 0.60% | Manganese for strength and hardness balance |
| Chemical Composition (P/S) | P ≤ 0.10%, S ≤ 0.045% | Controlled for improved corrosion resistance and ductility |
| Tensile Strength | 270–560 MPa | Per EN 10346 / ASTM A755; varies by grade (e.g., S280GD: ≥ 360 MPa) |
| Yield Strength | 220–420 MPa | S280GD: ≥ 280 MPa; S350GD: ≥ 350 MPa (EN 10346) |
| Elongation | ≥ 16–22% | Minimum elongation (A80) ensuring good bending and forming performance |
| Thickness Range | 0.12 – 1.50 mm | Common building use: 0.30–0.80 mm; custom thickness available |
| Width Range | 600 – 1,250 mm | Standard widths: 750 mm, 900 mm, 1,000 mm, 1,200 mm |
| Paint Coating | Top coat: 15–25 μm; Primer: 5–7 μm; Back coat: 7–10 μm | Polyester (PE), PVDF, SMP, HDP coating options available |
| Surface Finish | Smooth / Embossed / Matte / Glossy | RAL color customization available; gloss level 10–80 GU |
| Application | Roofing, wall cladding, sandwich panels, warehouses, factories | Widely used in industrial, commercial, and residential metal buildings |
| Certification | ISO 9001, SGS, BV, CE | Third-party inspection and mill test certificate (MTC) available |
| Packaging | Coil or sheet; waterproof paper + steel strip + wooden pallet | Coil weight: 3–8 MT; export seaworthy packaging standard |
| MOQ | 25 MT per order | Mixed colors and specifications accepted for full container load (FCL) |
Initial coating adhesion concern — supplier resolved it quickly
First order of 22 tons of 0.47 mm corrugated sheets for a school roofing project in Leeds. On inspection, approximately 3% of panels in one coil showed minor primer adhesion inconsistency at the cut edges, flagged against our EN 10169 acceptance criteria. Raised the issue with the supplier immediately — they responded within four hours, arranged a third-party inspection, and replaced the affected coil within eight business days at no extra cost. Remaining 97% of material was fully compliant. The after-sales response was genuinely professional and we are willing to trial a second order.
First order of 22 tons of 0.47 mm corrugated sheets for a school roofing project in Leeds. On inspection, approximately 3% of panels in one coil showed minor primer adhesion inconsistency at the cut edges, flagged against our EN 10169 acceptance criteria. Raised the issue with the supplier immediately — they responded within four hours, arranged a third-party inspection, and replaced the affected coil within eight business days at no extra cost. Remaining 97% of material was fully compliant. The after-sales response was genuinely professional and we are willing to trial a second order.
