| Property | Parameter | Description |
|---|---|---|
| Product Name | Roofing Sheets for Industrial Buildings | Profiled metal roofing panels designed for factories, warehouses, and industrial facilities |
| Material Grade | S350GD / DX51D+Z / G550 | International equivalents: ASTM A653 Grade 50, EN 10346 DX51D+Z, AS 1397 G550 |
| Standard Compliance | ASTM A653 / EN 10346 / AS 1397 / GB/T 12755 | Meets international standards for structural and non-structural roofing applications |
| Chemical Composition | C ≤0.12%, Mn ≤0.60%, P ≤0.045%, S ≤0.045%, Si ≤0.50% | Low-carbon steel base with controlled alloying for formability and strength |
| Tensile Strength | 350–550 MPa | Per EN 10346 / ASTM A653; higher grades available for heavy-load industrial roofing |
| Yield Strength | 280–500 MPa | Minimum yield strength ensures structural integrity under wind and snow loads |
| Elongation | ≥12% (A80mm) | Adequate ductility for roll-forming and site installation without cracking |
| Sheet Thickness | 0.3 mm – 1.2 mm (base metal) | Common industrial grades: 0.47 mm, 0.55 mm, 0.70 mm, 1.0 mm BMT |
| Sheet Width | Effective width: 760 mm – 1000 mm; Coil width up to 1250 mm | Profile-dependent effective coverage width; custom widths available |
| Sheet Length | 1800 mm – 12000 mm (custom cut-to-length) | Standard lengths 3 m, 6 m, 9 m; longer sheets available for large-span roofs |
| Coating / Surface Finish | Hot-dip galvanized (Z100–Z275 g/m²), Galvalume (AZ150), PVDF/PE color coating 25–35 μm | Zinc or zinc-aluminum alloy coating with optional polyester or PVDF topcoat for corrosion resistance |
| Profile Type | Corrugated, Trapezoidal (IBR), Standing Seam, Sinusoidal | Various rib heights (18 mm–50 mm) to suit span requirements and load conditions |
| Application | Industrial factories, warehouses, logistics centers, steel structure buildings, agricultural sheds | Suitable for new construction and re-roofing of industrial and commercial structures |
| Certification | ISO 9001, CE Marking, FM Approval (optional), SGS / BV Third-party Inspection | Quality management and product conformity certifications for global B2B procurement |
| Packaging | Bundled in steel strapping with waterproof PE film; wooden pallet or steel cradle | Export-standard packaging; max bundle weight ≤3 MT for safe handling and shipping |
| MOQ | 5 MT per order (standard profiles); 25 MT for custom profiles | Mixed profiles and colors accepted above minimum order; FOB / CIF terms available |
Initial delivery delay — resolved satisfactorily with good communication
We ordered 0.80 mm G550 trapezoidal roofing sheets (Z275, ASTM A653) for a manufacturing plant project in Hyderabad with a firm four-week delivery requirement. The shipment arrived eight days late due to port congestion, which caused a short schedule delay on our end. However, the supplier communicated proactively once the delay was identified, provided daily status updates, and offered a partial freight credit as compensation. Panel quality itself — coating uniformity, profile accuracy, and mechanical properties — was fully compliant with specifications. Issue was logistical, not product-related, and was handled professionally.
We ordered 0.80 mm G550 trapezoidal roofing sheets (Z275, ASTM A653) for a manufacturing plant project in Hyderabad with a firm four-week delivery requirement. The shipment arrived eight days late due to port congestion, which caused a short schedule delay on our end. However, the supplier communicated proactively once the delay was identified, provided daily status updates, and offered a partial freight credit as compensation. Panel quality itself — coating uniformity, profile accuracy, and mechanical properties — was fully compliant with specifications. Issue was logistical, not product-related, and was handled professionally.
