| Property | Parameter | Description |
|---|---|---|
| Product Name | Roofing Sheets for Warehouse Buildings | Corrugated / trapezoidal profiled metal roofing panels for industrial and warehouse structures |
| Material Grade | S280GD, S350GD (EN); ASTM A653 Grade 33/50; DX51D+Z (EN 10346) | Hot-dip galvanized or Galvalume steel; equivalent to SGCC / SGCH (JIS G3302) |
| Standard Compliance | EN 10346, ASTM A653 / A792, JIS G3302, GB/T 2518 | Meets international standards for continuous hot-dip coated flat steel products |
| Chemical Composition (C) | ≤ 0.12% | Low carbon content ensures formability and weldability |
| Chemical Composition (Mn) | ≤ 0.60% | Manganese for strength and hardness balance |
| Chemical Composition (P / S) | P ≤ 0.10% / S ≤ 0.045% | Controlled phosphorus and sulfur for improved ductility |
| Chemical Composition (Si) | ≤ 0.50% | Silicon content for coating adhesion performance |
| Tensile Strength | 280–550 MPa | Per EN 10346 / ASTM A653; higher grades available for heavy-load warehouse roofing |
| Yield Strength | 220–420 MPa | Minimum yield strength ensuring structural rigidity under wind and snow loads |
| Elongation | ≥ 16–22% | Adequate elongation for roll-forming and profiling without cracking |
| Thickness Range | 0.3 mm – 1.2 mm (base metal); overall 0.35–1.5 mm with coating | Common warehouse roofing: 0.45 mm, 0.5 mm, 0.6 mm; custom thickness available |
| Width / Length | Width: 750–1250 mm effective; Length: 1000–12000 mm (customizable) | Standard effective coverage width 760 mm / 900 mm / 1000 mm; cut-to-length service available |
| Coating / Surface Finish | Galvanized Z60–Z275 g/m²; Galvalume AZ50–AZ150 g/m²; Color-coated PVDF / PE | Hot-dip zinc or zinc-aluminum alloy coating; optional polyester or PVDF color coating for UV resistance |
| Profile Type | Corrugated (18/76), Trapezoidal (T35, T45, IBR), Standing Seam | Various rib heights and pitches to suit warehouse span and load requirements |
| Application | Warehouse roofing, industrial sheds, logistics centers, cold storage facilities, agricultural buildings | Suitable for single-span and multi-span steel structure warehouse roofs |
| Certification | ISO 9001, CE Marking, SGS, BV | Third-party inspection and quality management system certification available |
| Packaging | Bundled in steel strapping; waterproof kraft paper / PE film wrapping; wooden pallet or steel pallet | Export-standard seaworthy packaging; bundle weight typically 2–5 MT |
| MOQ | 5 MT per specification | Mixed specifications accepted; OEM profile and color available upon request |
Initial length tolerance issue — resolved quickly by supplier
Our first order of 0.5 mm S280GD color-coated trapezoidal panels (PVDF, 35 µm DFT) for a 15,000 sqm cold storage facility had an issue: approximately 3% of the 10,000 mm panels measured 15–20 mm short of specified length, causing minor installation delays. I raised this immediately and the supplier responded within hours, issued a credit note for the affected panels, and shipped replacement lengths within 10 days. Subsequent quality has been fine. The responsiveness was reassuring and we have since placed a follow-on order. Worth noting for first-time buyers to specify tight length tolerances upfront.
