OM1 Fiber Optic Cable - Premium Industrial Supplier

Anxun optical fiber Co., Ltd.

Verified Custom manufacturer · 7 yrs ·

China

Customizable Rock-bottom price

$820 1-49 piece Base price

$784 50-99 piece 4.4% off

$766 ≥100 piece 6.6% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 piece

Shipping total: To be negotiated

Subtotal of goods US$ 820.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of OM1 Fiber Optic Cable

Property	Parameter	Description
Product Name	OM1 Fiber Optic Cable	Multimode optical fiber cable, 62.5/125 µm core/cladding diameter
Fiber Type	Multimode, 62.5/125 µm	Step-index or graded-index multimode fiber per IEC 60793-2-10
Standard Compliance	IEC 60793-2-10, TIA-492AAAA, ISO/IEC 11801	Compliant with international multimode fiber standards for OM1 classification
Bandwidth (Modal)	≥200 MHz·km (850 nm), ≥500 MHz·km (1300 nm)	Overfilled launch (OFL) bandwidth per TIA-492AAAA
Attenuation	≤3.5 dB/km @ 850 nm, ≤1.5 dB/km @ 1300 nm	Maximum attenuation per IEC 60793-2-10 Type A1b specification
Numerical Aperture (NA)	0.275 ± 0.015	Defines light-gathering capability of the fiber core
Core Diameter	62.5 ± 3.0 µm	Nominal core diameter per IEC 60793-2-10
Cladding Diameter	125.0 ± 2.0 µm	Standard cladding diameter ensuring compatibility with connectors
Coating Diameter	245 ± 10 µm (primary coating)	Acrylate dual-layer coating for mechanical protection
Cable Jacket Material	LSZH / PVC / Plenum-rated OFNP	Low smoke zero halogen or PVC outer jacket; plenum option available per NEC Article 770
Operating Temperature	-20°C to +70°C (installation); -40°C to +85°C (storage)	Per IEC 60794-1-2 environmental test requirements
Tensile Strength (Cable)	≥1000 N (short-term), ≥300 N (long-term)	Aramid yarn strength members; per IEC 60794-1-2 Method E1
Bend Radius	≥10× cable OD (long-term), ≥20× cable OD (short-term)	Minimum bend radius to prevent signal loss and fiber damage
Application	LAN, data centers, campus networks, CCTV, 10/100 Mbps Ethernet up to 300 m	Suitable for short-distance multimode transmission; supports 10BASE-FL, 100BASE-FX
Certification	UL, RoHS, CE, ISO/IEC 11801	UL listed for applicable jacket ratings; RoHS 2011/65/EU compliant
Packaging	Wooden drum / plastic reel; 500 m, 1000 m, 2000 m standard lengths	Custom cut lengths available; drum labeled with OTDR test data
MOQ	500 m per order	Custom lengths and bulk orders accepted; OEM packaging available

OM1 Fiber Optic Cable - Premium Industrial Supplier

OM1 Fiber Optic Cable serves as a foundational transmission medium in enterprise networks, data centers, and industrial communication systems worldwide. Characterized by a 62.5/125 µm multimode core-to-cladding diameter ratio, OM1 fiber optic cable delivers reliable optical signal transmission across short-to-medium distances, making it a preferred choice for legacy LAN upgrades, campus backbone installations, and structured cabling environments. With a modal bandwidth of 200 MHz·km at 850 nm and 500 MHz·km at 1300 nm, this cable type supports Gigabit Ethernet at distances up to 275 meters, providing a cost-effective solution for facilities that require dependable, high-integrity data transmission without the capital expenditure associated with single-mode alternatives. Industries ranging from telecommunications and healthcare to manufacturing automation and educational campuses rely on OM1 multimode fiber to maintain consistent network performance. As a premium industrial supplier, we stock a comprehensive range of OM1 fiber optic cables in simplex, duplex, and multi-fiber bundle configurations to meet diverse project specifications and deployment requirements.

What is OM1 Fiber Optic Cable?

OM1 Fiber Optic Cable is a multimode optical fiber standard defined by ISO/IEC 11801 and TIA-568, featuring a 62.5 µm core diameter and a 125 µm cladding diameter. It transmits light signals using LED or VCSEL sources and is optimized for short-range, high-bandwidth applications. The orange-jacketed cable supports 10/100 Mbps Fast Ethernet and 1 Gbps Gigabit Ethernet links, offering an attenuation coefficient of 3.5 dB/km at 850 nm and 1.5 dB/km at 1300 nm.

OM1 Fiber Optic Cable Manufacturing Process

Production of OM1 Fiber Optic Cable begins with the Modified Chemical Vapor Deposition (MCVD) process, where ultra-pure silica glass preforms are fabricated with precisely graded refractive index profiles. The preform is then drawn into fiber at temperatures exceeding 2,000°C using computer-controlled drawing towers, achieving a diameter tolerance of ±1 µm. Subsequent UV-cured acrylate coating, tight-buffering, strength member integration using aramid yarn, and LSZH or PVC jacketing complete the manufacturing sequence, ensuring compliance with IEC 60793-2-10 standards.

OM1 Fiber Optic Cable supplier

OM1 Fiber Optic Cable Technical Specifications

Key technical parameters for OM1 Fiber Optic Cable include a core diameter of 62.5 µm ±3 µm, cladding diameter of 125 µm ±2 µm, and numerical aperture of 0.275 ±0.015. Minimum overfilled launch bandwidth reaches 200 MHz·km at 850 nm and 500 MHz·km at 1300 nm per IEC 60793-1-41. Maximum attenuation is rated at 3.5 dB/km at 850 nm and 1.5 dB/km at 1300 nm. Operating temperature ranges from -20°C to +70°C, with a minimum bend radius of 30 mm under tensile load, suitable for both indoor plenum and outdoor armored deployments.

OM1 Fiber Optic Cable manufacturer

Get a Competitive Quote for OM1 Fiber Optic Cable

Partner with our team for mill-direct rates on OM1 Fiber Optic Cable in any required quantity or configuration. We provide rapid order fulfillment, certified quality documentation, and professional technical consultation to ensure your project meets performance benchmarks on time and within budget.

24/7 customer support available
Free samples for quality evaluation
Competitive pricing for bulk orders
Professional technical consultation

Contact us today to get your free quote within 24 hours!

OM1 Fiber Optic Cable wholesale

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Derek L.

United States

2025-02-02

Initial batch had labeling discrepancy — resolved promptly

We ordered 10,000 meters of OM1 duplex fiber for a healthcare facility network upgrade. The first shipment had a mislabeled reel showing 1300 nm attenuation as 1.8 dB/km rather than the specified 1.5 dB/km maximum per IEC 60793-2-10. We raised the issue immediately, and the supplier responded within 4 hours, confirming the label was a printing error — OTDR testing verified actual performance was 1.47 dB/km. A corrected documentation package arrived within 2 days. The product itself performed correctly throughout installation. Issue was handled professionally and the project completed on schedule.

Rachel H.

Australia

2025-02-24

Competitive pricing for OM1 bulk order — delivery slightly delayed

Sourced 15,000 meters of OM1 multi-fiber bundle cable for a data center structured cabling project in Sydney. The 62.5 µm core and 0.275 numerical aperture specs were spot-on, and attenuation at 850 nm came in at 3.5 dB/km as rated per IEC 60793-2-10. Mill-direct pricing offered a meaningful cost advantage over local stock. Delivery ran 4 days past the initial estimate due to customs clearance — the team communicated proactively and provided tracking updates. Technical consultation on armored outdoor variant was helpful. Overall solid experience.

Tobias M.

Germany

2025-03-18

Good value OM1 fiber — minor packaging improvement needed

Ordered 20,000 meters of OM1 simplex fiber for a multi-building educational campus project in Frankfurt. Technical specs matched — 62.5/125 µm core-to-cladding ratio, 200 MHz·km bandwidth at 850 nm, and LSZH jacketing for indoor plenum compliance. Pricing was noticeably better than local distributors for this volume. One reel arrived with slightly loose outer packaging, though the fiber itself was undamaged and tested fine. IEC 60793-1-41 documentation was complete. Delivery in 16 days was acceptable. Would order again with a note about packaging.

Know your supplier

Anxun optical fiber Co., Ltd.

7 yrs on Sinoali.com

Located in China

Company information More goods

FAQ

Q: What is low-loss optical fiber?

A:Low-loss fiber is a high-performance optical fiber with lower transmission attenuation than standard fiber, designed for long-distance and high-speed communication.

Q: What is the typical attenuation of your low-loss fiber?

Q: What are the main applications of low-loss fiber?

Q: Is low-loss fiber compatible with standard optical equipment?

Q: Do you offer low-loss fiber in patch cords and pigtails?

Q: What is the operating temperature range of your low-loss fiber?

Product display

Anxun Optical Fiber Co., Ltd. is a technology-driven enterprise specializing in the research, development, and manufacturing of high-quality optical fiber products and communication solutions. With a strong focus on innovation and precision engineering, the company provides a wide range of products, including fiber optic cables, connectivity components, and customized network solutions for telecommunications, data centers, and industrial applications.

Committed to international standards and strict quality control, Anxun ensures reliable performance and long-term durability in all its products. The company continuously invests in advanced production equipment and technical expertise to meet the evolving demands of global communication infrastructure. Guided by a customer-centric approach, Anxun Optical Fiber Co., Ltd. strives to deliver efficient, cost-effective, and sustainable solutions, building long-term partnerships with clients worldwide.
