Prime PPGI Color Coated Steel Sheet - Mill Supplier
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 ton
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of Prime Quality PPGI Color Coated Steel Sheet
| Property | Parameter | Description |
|---|---|---|
| Product Name | Prime Quality PPGI Color Coated Steel Sheet | Pre-painted galvanized iron steel sheet with organic coating on zinc-coated substrate |
| Material Grade | DX51D+Z / SGCC / CS Type B | Equivalent grades: EN 10346 DX51D+Z, JIS G3302 SGCC, ASTM A653 CS Type B |
| Standard Compliance | ASTM A755 / EN 10169 / JIS G3312 / GB/T 12754 | Meets international standards for continuously organic-coated flat-rolled steel |
| Chemical Composition | C ≤ 0.12%, Mn ≤ 0.60%, P ≤ 0.045%, S ≤ 0.045%, Si ≤ 0.50% | Base metal composition per EN 10346; zinc coating: Zn ≥ 99.5% |
| Tensile Strength | 270–500 MPa | Varies by grade; DX51D+Z min. 270 MPa per EN 10346; SGCC min. 270 MPa per JIS G3302 |
| Yield Strength | 140–420 MPa | DX51D+Z: 140–300 MPa; higher-strength grades available up to S550GD+Z |
| Elongation | ≥ 22% | Minimum elongation at fracture (A80mm) per EN 10346 for DX51D grade |
| Coating Type | Polyester (PE) / PVDF / SMP / HDP | Top coat 15–25 μm PE standard; PVDF 25 μm for superior weather resistance |
| Zinc Coating Weight | Z60–Z275 (g/m²) | Both sides combined; Z120 (120 g/m²) most common for general construction use |
| Thickness Range | 0.14–1.50 mm (base metal) | Total thickness including coating; tolerance per EN 10143 or ASTM A924 |
| Width Range | 600–1,250 mm | Standard coil width; slit-to-width service available; sheet length customizable |
| Surface Finish | Smooth / Embossed / Matte / High Gloss | RAL color system available; 60° gloss value 30–85 GU depending on finish type |
| Application | Roofing, wall cladding, home appliances, garage doors, sandwich panels | Widely used in construction, automotive interiors, and household appliance industries |
| Certification | ISO 9001 / SGS / BV / CE | Mill test certificate (MTC) per EN 10204 3.1 available upon request |
| Packaging | Standard export seaworthy coil packaging | Eye-to-sky or eye-to-wall; moisture-proof paper + steel strip banding; wooden pallet optional |
| MOQ | 25 MT per order | Mixed specifications accepted; full container load (FCL) ~25 MT per 20' GP container |
Prime PPGI Color Coated Steel Sheet - Mill Supplier
Prime quality PPGI color coated steel sheet stands as one of the most versatile and performance-driven materials in modern construction and manufacturing industries. PPGI — Pre-Painted Galvanized Iron — combines a hot-dip galvanized or galvalume substrate with a factory-applied polymer coating system, delivering outstanding anti-corrosion properties alongside a broad spectrum of aesthetic options. From roofing panels and wall cladding to household appliances and automotive components, this material finds extensive application in environments that demand both structural integrity and visual appeal. As a mill-direct supplier, we offer certified prime-grade PPGI sheets with zinc coating weights ranging from Z60 to Z275 g/m², paint film thicknesses from 5 µm to 25 µm, and a full RAL/Pantone color palette. Our products comply with ASTM A755, EN 10169, and JIS G3312 standards, ensuring consistent quality across every coil and sheet we dispatch to global markets.
What is Prime Quality PPGI Color Coated Steel Sheet?
Prime quality PPGI color coated steel sheet is a cold-rolled, hot-dip galvanized steel substrate that undergoes a continuous coil coating process, applying primer and topcoat layers to both surfaces before forming. The result is a corrosion-resistant, UV-stable panel with a yield strength typically ranging from 280 MPa to 550 MPa, a base metal thickness of 0.13 mm to 1.5 mm, and coil widths up to 1,500 mm. It serves critical roles in roofing, façade systems, garage doors, and light-gauge steel framing.
Prime Quality PPGI Color Coated Steel Sheet Manufacturing Process
Production begins with prime cold-rolled galvanized coils entering a continuous coating line at speeds up to 180 m/min. The strip is chemically cleaned, passivated, and pre-treated with a chromate-free conversion layer before a roller-applied polyester, SMP, or PVDF primer is cured in a thermal oven at 230°C–260°C. A topcoat — typically 15 µm to 25 µm dry film thickness — is then applied, followed by a back coat of 5 µm to 12 µm, ensuring balanced performance on both faces. Finished coils are tension-leveled and slit to customer specifications.
Prime Quality PPGI Color Coated Steel Sheet Technical Specifications
Our PPGI color coated steel sheet is produced to the following verified parameters: base metal thickness 0.13 mm–1.5 mm (±0.02 mm tolerance); coil width 600 mm–1,500 mm; zinc coating Z60–Z275 g/m² per ASTM A653; topcoat dry film thickness 15–25 µm; pencil hardness ≥ 2H; T-bend flexibility T1–T2; 60° gloss value 30–85 GU; salt spray resistance ≥ 1,000 hours per ASTM B117; and tensile strength 280–550 MPa depending on grade. Available coatings include standard polyester (PE), high-durability silicon-modified polyester (SMP), and premium PVDF for extreme-weather applications.
Get a Competitive Quote for Prime Quality PPGI Color Coated Steel Sheet
Partner with our mill-direct team to access cost-effective pricing, fast lead times, and certified prime PPGI color coated steel sheet tailored to your project specifications. We support small trial orders and large-volume contracts with equal dedication. Reach out now and receive your detailed quotation within 24 hours.
- 24/7 customer support available
- Free samples for quality evaluation
- Competitive pricing for bulk orders
- Professional technical consultation
Contact us today to get your free quote within 24 hours!
