Profiled Steel Sheet - ASTM Certified Manufacturer |

Xinpeng Color Coating Co., Ltd.

Verified Custom manufacturer · 2 yrs ·

China

Customizable Rock-bottom price

$598 1-49 ton Base price

$572 50-99 ton 4.3% off

$559 ≥100 ton 6.5% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 ton

Shipping total: To be negotiated

Subtotal of goods US$ 598.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Profiled Steel Sheet

Property	Parameter	Description
Product Name	Profiled Steel Sheet	Cold-formed or hot-rolled corrugated/trapezoidal steel sheet for structural use
Material Grade	S250GD, S280GD, S320GD, S350GD, S390GD, S420GD (EN); ASTM A653 SS Grade 33/37/40/50; Q235, Q345 (GB)	International equivalent grades available upon request
Standard Compliance	EN 10346, ASTM A653/A792, JIS G3302, GB/T 12755	Meets international structural and coating standards
Chemical Composition (C)	≤ 0.20%	Carbon content controlling weldability and strength
Chemical Composition (Mn)	≤ 1.70%	Manganese for enhanced tensile properties
Chemical Composition (P/S)	P ≤ 0.040%, S ≤ 0.040%	Controlled for improved ductility and toughness
Tensile Strength	320–550 MPa	Per EN 10346 / ASTM A653; varies by grade
Yield Strength	250–420 MPa	Minimum yield strength depending on material grade
Elongation	≥ 16–24%	Measured on 80 mm gauge length per EN 10346
Base Metal Thickness	0.3–3.0 mm	Excluding coating; custom thickness available
Sheet Width	600–1250 mm (effective); up to 1500 mm (coil width)	Effective coverage width depends on profile type
Sheet Length	1000–12000 mm	Custom cut-to-length available
Profile Type	Trapezoidal (T18, T35, T76), Corrugated (18/76), Standing Seam	Profile height and pitch customizable per project
Surface Finish	Hot-dip galvanized (Z100–Z275 g/m²), Galvalume (AZ150), Pre-painted PPGI/PPGL	Color coating per RAL standard; anti-corrosion treatment available
Application	Roofing, wall cladding, floor decking, industrial buildings, warehouses, cold storage	Widely used in construction and infrastructure projects
Certification	ISO 9001, CE Marking, SGS, BV	Third-party inspection and mill test certificates available
Packaging	Bundled in steel straps, wrapped with waterproof film, wooden pallet or steel pallet	Export seaworthy packaging standard
MOQ	5 Metric Tons	Mixed specifications accepted; OEM orders welcome

Profiled Steel Sheet - ASTM Certified Manufacturer

Profiled steel sheet is a cornerstone structural material trusted across construction, industrial, and infrastructure sectors worldwide. Manufactured through precision cold-roll forming or hot-rolling processes, these sheets feature corrugated, trapezoidal, or ribbed cross-sectional profiles that dramatically enhance load-bearing capacity without adding excessive weight. As an ASTM-certified manufacturer, we supply profiled steel sheets that conform to ASTM A653, A792, and EN 10346 standards, ensuring dimensional accuracy and consistent mechanical performance across every batch. Whether you are sourcing material for roofing systems, wall cladding, floor decking, or composite slab construction, our profiled sheets deliver the structural integrity and long-term durability your project demands. With mill-direct rates and a global logistics network, we serve contractors, developers, and steel distributors across North America, Europe, Southeast Asia, and the Middle East — providing reliable supply chain solutions and full technical documentation for every shipment.

Profiled Steel Sheet supplier

What is Profiled Steel Sheet?

Profiled steel sheet refers to flat-rolled steel that has been formed into a defined geometric cross-section — typically trapezoidal, sinusoidal, or ribbed — to maximize structural stiffness and spanning capability. The base material is generally hot-dip galvanized steel, Galvalume (55% Al-Zn alloy coated), or pre-painted steel coil. These profiles serve critical roles in roof decking, composite floor systems, façade cladding, and industrial building envelopes where both strength and lightweight construction are required.

Profiled Steel Sheet Manufacturing Process

Production begins with premium-grade steel coil, typically with a base metal thickness ranging from 0.3 mm to 1.5 mm, which is fed through a continuous roll-forming line comprising 12 to 24 forming stations. Each station progressively shapes the flat strip into the target profile geometry. For corrosion protection, substrates receive a hot-dip zinc coating of 60–275 g/m² (Z60–Z275 per EN 10346) or an AZ150 Galvalume coating. Optional PVDF or polyester paint systems are applied via coil-coating lines before or after profiling, achieving a dry film thickness of 25–35 µm for exterior-grade finishes.

Profiled Steel Sheet manufacturer

Profiled Steel Sheet Technical Specifications

Our profiled steel sheets are available in the following standard parameters:

Base material: Structural steel S280GD / S350GD per EN 10346; Grade 33/50 per ASTM A653
Yield strength: 280–550 MPa depending on grade
Tensile strength: 360–600 MPa minimum
Base metal thickness: 0.30 mm – 1.50 mm (tolerance ±0.02 mm)
Effective cover width: 750 mm – 1,200 mm
Profile height: 18 mm – 135 mm (custom profiles available)
Zinc coating mass: Z60 – Z275 g/m² (double-sided total)
Panel length: Cut-to-length from 1,000 mm to 12,000 mm
Surface finish: Bare galvanized, Galvalume AZ150, or pre-painted (RAL color matching)

All products are supplied with mill test certificates (MTC) in accordance with EN 10204 3.1, and dimensional inspection reports are available upon request. Fire resistance and acoustic performance data can be provided for composite deck applications.

Get a Competitive Quote for Profiled Steel Sheet

Partner with an ASTM-certified manufacturer that delivers mill-direct pricing, consistent quality, and on-time shipment. Whether you need standard trapezoidal profiles or custom-engineered cross-sections, our technical team is ready to support your specification requirements and provide a detailed quotation within 24 hours of inquiry submission.

Profiled Steel Sheet wholesale

24/7 customer support available
Free samples for quality evaluation
Competitive pricing for bulk orders
Professional technical consultation

Contact us today to get your free quote within 24 hours!

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Charlotte P.

United Kingdom

2025-02-02

Initial colour batch inconsistency — resolved promptly and professionally

Our first order of 30 tons of pre-painted profiled sheet in RAL 5010 showed a slight colour variance between two coils when panels were laid side by side on site. We raised this immediately with the customer support team. To their credit, they responded within hours, arranged a third-party colour measurement report, and shipped replacement panels for the affected coils within two weeks at no additional cost. The replacement batch was perfectly consistent. The issue itself was disappointing but the resolution was handled professionally. We have since placed a follow-up order and the quality has been correct throughout.

Nadia A.

UAE

2025-02-24

Competitive mill pricing on pre-painted sheet — good documentation package

We sourced 70 tons of pre-painted profiled sheet, 0.50 mm S280GD with polyester coating in RAL 9002, for warehouse wall cladding projects across Dubai and Abu Dhabi. The price per ton was noticeably lower than our previous European supplier for equivalent EN 10346 specification. Documentation — including MTC, packing list, and dimensional inspection report — was complete and well-organised, which matters for customs clearance here. We'd rate technical response as four stars rather than five only because one email took 36 hours to answer, but overall the procurement experience was smooth and professional.

Rachel B.

Australia

2025-03-18

Good value on Galvalume corrugated sheet — minor lead time variance

We purchased 45 tons of corrugated profiled sheet in AZ150 Galvalume, 0.42 mm base thickness for residential roofing supply in Queensland. The product quality itself is solid — coating adhesion is good, profile depth is consistent, and the MTCs reference ASTM A792 correctly. Our only note is that delivery ran four days longer than the original estimate due to port scheduling, though we were kept informed throughout. Pricing is genuinely competitive compared to local suppliers for this specification. We would order again and have already requested a quote for a second consignment.

Know your supplier

Xinpeng Color Coating Co., Ltd.

2 yrs on Sinoali.com

Located in China

Company information More goods

Company Profile

Xinpeng Color Coating Co., Ltd. is a specialized industrial enterprise focusing on high-performance Color Coated Steel Sheet production and global export business. We integrate independent research, production and trade, supplying standard and custom color coated steel sheets with complete material grades and color options.

Equipped with international-level production equipment and sophisticated testing instruments, we implement full-process quality inspection to guarantee corrosion resistance, surface flatness and coating durability. With abundant spot inventory, professional export packaging and efficient logistics scheduling, we support bulk orders and short lead times. Our products serve construction engineering, automotive industry, household appliances, shipbuilding and energy sectors. We uphold integrity and innovation, commit to tailored solutions and stable supply for worldwide B2B customers.
