| Property | Parameter | Description |
|---|---|---|
| Product Name | Exterior Wall Cladding Steel Sheet | Pre-coated or galvanized steel sheet designed for building facade and exterior wall cladding systems |
| Material Grade | DX51D, DX52D, S250GD, S350GD (EN); ASTM A653 CS/SS; JIS G3302 SGCC/SGCH | Hot-dip galvanized or Galvalume (AZ) coated structural steel; equivalent to GB/T 2518 DC51D+Z |
| Standard Compliance | EN 10346, ASTM A653/A792, JIS G3302/G3321, GB/T 2518 | Complies with international standards for continuous hot-dip coated flat steel products for cold forming |
| Chemical Composition | C ≤ 0.12%, Mn ≤ 0.60%, P ≤ 0.10%, S ≤ 0.045%, Si ≤ 0.50% | Low-carbon steel chemistry ensuring good formability, weldability, and corrosion resistance |
| Tensile Strength | 270–550 MPa (grade dependent) | DX51D: 270–500 MPa; S350GD: 420–550 MPa per EN 10346; ASTM A653 SS Grade 33: ≥310 MPa |
| Yield Strength | 140–420 MPa | DX51D: ≥140 MPa; S250GD: ≥250 MPa; S350GD: ≥350 MPa per EN 10346 |
| Elongation | ≥16%–26% (A80mm) | DX51D: ≥22%; S350GD: ≥16% per EN 10346; ensures adequate formability for profiling and roll-forming |
| Coating Type | Z (Zinc), AZ (Galvalume/Zn-Al-Mg), PVDF, PE, SMP | Zinc coating: Z60–Z275 g/m²; Galvalume AZ50–AZ150; PVDF/PE organic top coat 20–50 μm |
| Thickness Range | 0.30 mm – 2.00 mm | Standard cladding profiles: 0.40–0.80 mm; structural panels: up to 2.00 mm; tolerance per EN 10143 |
| Width Range | 600 mm – 1,500 mm | Common coil widths: 914 mm, 1,000 mm, 1,219 mm, 1,250 mm; custom slit widths available |
| Length / Form | Coil or cut-to-length sheet; coil ID 508/610 mm | Coil weight up to 10 MT; sheet length 1,000–6,000 mm; profiled panels available on request |
| Surface Finish | Regular Spangle, Zero Spangle, Skin-passed, Embossed, Color-coated (RAL) | Top coat: PVDF or PE in full RAL palette; back coat: 5–10 μm epoxy primer; smooth or textured finish |
| Application | Exterior wall cladding, facade panels, roof sheeting, curtain walls, industrial building envelopes | Suitable for commercial, residential, and industrial construction; compatible with concealed-fix and exposed-fix systems |
| Certification | ISO 9001, CE Marking (EN 10346), SGS, BV, TÜV | Mill test certificate (MTC) per EN 10204 3.1 available; fire classification per EN 13501-1 on request |
| Packaging | Coils: waterproof paper + steel strip banding; Sheets: wooden pallet + stretch wrap | Export seaworthy packaging; moisture-proof inner wrapping; each coil/bundle labeled with heat number and specs |
| MOQ | 5 MT per specification | Mixed specifications accepted for orders ≥25 MT; sample order (≤500 kg) available for qualification testing |
Initial color inconsistency flagged — supplier resolved it professionally
Ordered 45 tonnes of 0.8 mm polyester-coated cladding in RAL 9006 for a logistics center in Brisbane. On arrival, approximately 8% of panels in the first container showed a slight gloss variation compared to approved samples — noticeable under direct Queensland sunlight. We raised this immediately and the supplier responded within one business day, arranged independent color measurement per ASTM D2244, confirmed the variance, and replaced the affected panels within 12 days at no additional cost. The replacement batch was spot-on. The issue was frustrating initially, but the resolution was handled transparently and efficiently. Comfortable ordering again.
Ordered 45 tonnes of 0.8 mm polyester-coated cladding in RAL 9006 for a logistics center in Brisbane. On arrival, approximately 8% of panels in the first container showed a slight gloss variation compared to approved samples — noticeable under direct Queensland sunlight. We raised this immediately and the supplier responded within one business day, arranged independent color measurement per ASTM D2244, confirmed the variance, and replaced the affected panels within 12 days at no additional cost. The replacement batch was spot-on. The issue was frustrating initially, but the resolution was handled transparently and efficiently. Comfortable ordering again.
