| Property | Parameter | Description |
|---|---|---|
| Product Name | Metal Roofing Color Steel Sheet | Pre-painted galvanized/galvalume steel sheet for roofing applications |
| Material Grade | DX51D, DX52D, S280GD, S350GD | Equivalent to ASTM A755, JIS G3312, EN 10346 substrate grades |
| Standard Compliance | GB/T 12754, EN 10169, ASTM A755/A755M, JIS G3312 | International standards for prepainted metal coil and sheet |
| Chemical Composition | C≤0.12%, Mn≤0.60%, P≤0.10%, S≤0.045%, Si≤0.50% | Base steel chemistry per substrate grade requirements |
| Tensile Strength | 270–550 MPa | Varies by grade; S350GD min. 420 MPa per EN 10346 |
| Yield Strength | 220–420 MPa | S280GD min. 280 MPa; S350GD min. 350 MPa |
| Elongation | ≥16–22% | Measured at A80 gauge length per EN/GB standards |
| Base Metal Thickness | 0.14–1.20 mm | Total thickness including coating; common roofing: 0.35–0.80 mm |
| Sheet Width | 600–1,250 mm | Slit-to-width available; standard coil width 1,000/1,219 mm |
| Sheet Length | 1,000–6,000 mm (custom) | Cut-to-length or coil supply; corrugated/trapezoidal profiles available |
| Zinc/Alloy Coating | Z60–Z275 g/m²; AZ50–AZ150 g/m² | Hot-dip galvanized (GI) or Galvalume (GL/Zincalume) substrate |
| Top Coat Paint | PVDF (25 µm), SMP (20 µm), HDP (25 µm), Polyester (15–25 µm) | PVDF offers superior UV/weather resistance; RAL/custom colors available |
| Surface Finish | Smooth, Matte, Embossed, Textured | Color uniformity per ASTM D2244; gloss level 10–85 GU |
| Application | Industrial/commercial roofing, wall cladding, agricultural buildings, residential housing | Suitable for corrugated sheets, standing seam, and tile profiles |
| Certification | ISO 9001, CE Marking, SGS, BV | Third-party inspection and mill test certificate (MTC) available |
| Packaging | Coil on steel mandrel or cut sheets in bundles; waterproof paper + steel strip strapping | Export seaworthy packing; coil weight 3–8 MT typical |
| MOQ | 5 MT per color/specification | Mixed container orders accepted; lead time 15–25 days |
Initial color inconsistency resolved after supplier intervention
Our first order of 30 tonnes of 0.45 mm polyester-coated sheet in RAL 5015 showed a visible gloss variation between two coils — one measured 42 GU and the other 28 GU, against a specified 35 GU. We raised the issue immediately with the technical team, who investigated within 48 hours, confirmed a line calibration deviation on one production run, and arranged replacement coils at no additional freight cost. The replacement material was within spec and arrived within 18 days. The issue was handled professionally and we did not lose project time. Upgraded from the original concern; supplier accountability here is genuine.
