| Property | Parameter | Description |
|---|---|---|
| Product Name | PPGI Galvanized Steel Sheet | Pre-Painted Galvanized Iron / Hot-Dip Galvanized Steel Sheet at Competitive Price |
| Material Grade | DX51D, SGCC, CS Type B | Equivalent to EN 10346 DX51D+Z, JIS G3302 SGCC, ASTM A653 CS Type B |
| Standard Compliance | ASTM A653 / EN 10346 / JIS G3302 / GB/T 2518 | Meets international standards for hot-dip galvanized and pre-painted steel coils/sheets |
| Chemical Composition (C) | ≤ 0.12% | Low carbon content ensures good formability and weldability |
| Chemical Composition (Mn) | ≤ 0.60% | Manganese content per EN 10346 / GB/T 2518 specification |
| Chemical Composition (P / S) | P ≤ 0.045% / S ≤ 0.045% | Controlled phosphorus and sulfur for improved ductility |
| Tensile Strength | 270–500 MPa | Typical range per ASTM A653 / EN 10346; grade-dependent |
| Yield Strength | 140–420 MPa | Minimum yield strength varies by grade (e.g., DX51D: ≥ 140 MPa) |
| Elongation | ≥ 22% | Minimum elongation at fracture per EN 10346 for DX51D grade |
| Thickness Range | 0.12 mm – 3.0 mm | Base metal thickness; total thickness includes zinc + paint coating |
| Width Range | 600 mm – 1,500 mm | Standard coil/sheet width; custom widths available on request |
| Zinc Coating Weight | Z60 – Z275 (g/m²) | Both sides combined; options: Z60, Z80, Z120, Z180, Z275 per EN 10346 |
| Paint Coating | Top: 15–25 µm / Back: 5–10 µm | Polyester (PE), PVDF, SMP, or HDP; RAL color customizable |
| Surface Finish | Regular Spangle / Minimized Spangle / Zero Spangle | Smooth, flat surface suitable for painting and forming operations |
| Application | Roofing, Cladding, Appliances, Construction, Automotive Parts | Widely used in building panels, corrugated sheets, home appliances, and HVAC systems |
| Certification | ISO 9001, SGS, BV, Mill Test Certificate (MTC) | Third-party inspection available; full MTC provided per EN 10204 3.1 |
| Packaging | Coil / Sheet / Slit Strip | Eye-to-sky or eye-to-wall coil; waterproof paper + steel strip bundling |
| MOQ | 5 Metric Tons | Lower MOQ available for sample orders; bulk pricing for ≥ 25 MT |
Initial dimension issue resolved — quality now confirmed satisfactory
Our first order of 25 tons of PPGI at 0.25 mm thickness, 900 mm width, had a coil width tolerance discrepancy of approximately 3 mm on two coils, which caused fitment issues on our stamping line. We raised the issue immediately and the supplier's technical team responded within 12 hours, provided a formal non-conformance report, and arranged replacement coils at no additional cost. The replacement shipment arrived within 15 days and met ASTM dimensional tolerances fully. The after-sales handling was professional and restored our confidence. We have since placed a follow-up order.
