| Property | Parameter | Description |
|---|---|---|
| Product Name | Prefab House Color Steel Sheet | Pre-painted galvanized/galvalume steel sheet for prefabricated building panels |
| Material Grade | DX51D, S280GD, S350GD / SGCC, SGCH | International equivalents: DX51D+Z (EN), SGCC (JIS G3302), CS Type B (ASTM A653) |
| Standard Compliance | EN 10346, JIS G3302, ASTM A653, GB/T 12754 | Meets international standards for hot-dip zinc-coated and pre-painted steel coils |
| Chemical Composition (C) | ≤ 0.12% | Low carbon content ensures good formability and weldability |
| Chemical Composition (Mn) | ≤ 0.60% | Manganese content for structural strength |
| Chemical Composition (P/S) | P ≤ 0.045%, S ≤ 0.045% | Controlled phosphorus and sulfur for improved ductility |
| Tensile Strength | 270–560 MPa | Varies by grade; S280GD: ≥ 360 MPa, S350GD: ≥ 420 MPa (per EN 10346) |
| Yield Strength | 280–420 MPa | S280GD: ≥ 280 MPa; S350GD: ≥ 350 MPa; suitable for structural panel applications |
| Elongation | ≥ 16–20% | Minimum elongation at fracture (A80mm) ensuring panel formability |
| Zinc Coating Weight | Z60–Z275 g/m² (AZ50–AZ150 for Galvalume) | Double-side coating; heavier coating for enhanced corrosion resistance in outdoor use |
| Thickness Range | 0.3–1.2 mm | Common prefab panel thickness: 0.4 mm, 0.5 mm, 0.6 mm; custom available |
| Width Range | 600–1250 mm | Standard coil width; slit-to-width service available per project requirement |
| Surface Finish | PVDF / PE / SMP coating, 2-coat or 3-coat system | Top coat 20–25 μm; primer 5–7 μm; RAL color customizable; gloss level 10–80% |
| Application | Prefab house wall panels, roof panels, sandwich panels, modular buildings | Widely used in residential, industrial, commercial prefabricated structures |
| Certification | ISO 9001, CE Marking, SGS, BV | Third-party inspection available; RoHS compliant coating options |
| Packaging | Steel coil on wooden pallet, eye-to-sky or eye-to-wall, waterproof paper wrapped | Coil weight: 3–8 MT; inner diameter: 508 mm or 610 mm |
| MOQ | 25 MT per order | Mixed colors and specifications accepted above MOQ; sample available upon request |
Initial profiling issue resolved — quality now meets spec
Ordered 30 tons of 0.45 mm corrugated color steel sheet for temporary modular storage units. First delivery batch had inconsistent rib height — measured 1.5 mm below drawing spec on approximately 15% of panels, which would have caused fit issues during assembly. Raised the issue immediately with the technical team. They responded within 4 hours, arranged re-rolling of the affected panels, and shipped replacements within 6 business days at no additional cost. Replacement panels measured within ±0.3 mm of spec. The resolution process was handled professionally. Willing to reorder given how the problem was managed.
