Product details

Technical Specifications of PPGI Profiled Sheet

Property	Parameter	Description
Product Name	PPGI Profiled Sheet	Pre-Painted Galvanized Iron corrugated/trapezoidal profiled roofing and wall cladding sheet
Material Grade	DX51D+Z / SGCC / S280GD+Z	International equivalents: DX51D (EN 10346), SGCC (JIS G3302), CS Type B (ASTM A653)
Standard Compliance	EN 10169 / ASTM A755 / JIS G3312 / GB/T 12754	Covers pre-painted flat-rolled steel products for building applications
Chemical Composition (Base Steel)	C ≤ 0.12%, Mn ≤ 0.60%, P ≤ 0.045%, S ≤ 0.045%, Si ≤ 0.50%	Low-carbon steel substrate ensuring good formability and paintability
Base Metal Thickness	0.14 mm – 1.20 mm	Nominal thickness excluding coating; common roofing gauges: 0.30–0.80 mm
Zinc Coating Mass	Z60 – Z275 (60–275 g/m²)	Per EN 10346 / ASTM A653; heavier coating improves corrosion resistance
Paint Coating System	Top coat: 15–25 µm PE/PVDF/SMP; Primer: 5–7 µm; Back coat: 7–12 µm	Polyester (PE) standard; PVDF for high-durability/coastal environments
Tensile Strength	270 – 560 MPa	Per EN 10346 / JIS G3312; varies by grade (DX51D: ≥270 MPa, S280GD: ≥360 MPa)
Yield Strength	140 – 420 MPa	DX51D: ≥140 MPa; S280GD+Z: ≥280 MPa (EN 10346)
Elongation	≥ 22% (A80)	Measured per EN ISO 6892-1; ensures formability during roll-forming profiling
Profile Dimensions	Width: 750–1250 mm (effective); Length: 1000–12000 mm (customizable)	Common profiles: corrugated 18/76, trapezoidal T35, T45, T130; rib height 18–130 mm
Surface Finish	Smooth / Embossed / Matte / High-gloss	RAL color customization available; 60° gloss value 30–80 GU depending on finish
Application	Roofing, wall cladding, ceiling panels, industrial buildings, warehouses, agricultural structures	Suitable for residential, commercial, and industrial construction projects
Certification	ISO 9001, CE Marking, SGS, BV	Third-party inspection and mill test certificates (MTC) available per EN 10204 3.1
Packaging	Bundled in steel straps with waterproof kraft paper / PE film wrapping; wooden pallet or steel pallet	Export seaworthy packaging; bundle weight typically ≤ 3 MT for safe handling
MOQ	25 MT per order (mixed sizes acceptable)	Full container load (FCL) preferred; LCL available for sample orders ≥ 5 MT

PPGI Profiled Sheet - Mill Direct Factory Supplier |

PPGI profiled sheet serves as one of the most versatile and durable roofing and cladding solutions available in today's construction market. Manufactured from pre-painted galvanized iron coils that are cold-roll formed into precise corrugated or trapezoidal profiles, these sheets combine outstanding anti-corrosion properties with vibrant, long-lasting color finishes. They find extensive application in industrial warehouses, agricultural buildings, commercial complexes, residential roofing, and wall panel systems across global markets. With a zinc coating weight typically ranging from Z60 to Z275 g/m² and a polyester or PVDF paint layer of 15–25 microns on the top surface, PPGI profiled sheets deliver a service life exceeding 20 years under normal atmospheric conditions. As a mill-direct factory supplier, we provide cost-effective pricing, consistent quality control, and rapid lead times — making us the preferred sourcing partner for contractors, distributors, and construction developers worldwide.

PPGI profiled sheet manufacturer

What is PPGI Profiled Sheet?

PPGI profiled sheet is a structural panel produced by roll-forming pre-painted galvanized steel coil (PPGI) into corrugated, trapezoidal, or ribbed cross-sectional profiles. The base metal is hot-dip galvanized steel with a yield strength of 250–550 MPa, coated with chromate passivation, primer, and a topcoat finish. The profiled geometry significantly enhances load-bearing capacity and rigidity compared to flat sheet, making it ideal for roofing, wall cladding, and decking applications.

PPGI Profiled Sheet Manufacturing Process

Production begins with premium-grade PPGI coils sourced from certified steel mills. Coils undergo continuous uncoiling, leveling, and feeding into a multi-stand cold roll-forming machine that progressively shapes the steel into the designated profile geometry. Dimensional tolerances are held to ±1 mm on rib height and ±2 mm on panel width. Finished panels are cut to customer-specified lengths using a flying shear system, then stacked, inspected, and packaged with protective film for export-standard shipment.

PPGI Profiled Sheet Technical Specifications

Base material thickness ranges from 0.3 mm to 1.2 mm (BMT), with effective coverage widths of 750 mm to 1,050 mm depending on profile type. Zinc coating conforms to ASTM A653 / EN 10346 standards at Z60–Z275 g/m². Paint system comprises a 5–8 µm epoxy primer plus a 15–25 µm polyester topcoat (PVDF optional), achieving a pencil hardness of ≥2H and a T-bend flexibility rating of 0T–2T. Available profile types include corrugated 18/76, trapezoidal 25/207, and IBR 686. Standard panel lengths are 1,000–12,000 mm with custom cutting available. Colors are matched to RAL or custom specifications with ΔE ≤ 1.0 color tolerance.

PPGI profiled sheet supplier

Get a Competitive Quote for PPGI Profiled Sheet

Partner with our mill-direct facility to access the most cost-effective rates on PPGI profiled sheet without compromising on quality. Whether you require full container loads or mixed-profile orders, our dedicated sales team delivers tailored solutions with full documentation including mill test certificates, SGS inspection reports, and MSDS sheets.

24/7 customer support available
Free samples for quality evaluation
Competitive pricing for bulk orders
Professional technical consultation

Contact us today to get your free quote within 24 hours!

PPGI profiled sheet factory
