Clean Room Color Coated Steel Sheet - Mill Direct
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 ton
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of Clean Room Color Coated Steel Sheet
| Property | Parameter | Description |
|---|---|---|
| Product Name | Clean Room Color Coated Steel Sheet | Pre-painted galvanized/galvalume steel sheet for cleanroom panel systems |
| Material Grade | DX51D+Z / DX53D+Z / S280GD+Z | Equivalent to ASTM A653 CS/SS, JIS G3302 SGCC/SGCD, EN 10346 DX51D |
| Standard Compliance | GB/T 12754, EN 10169, ASTM A755 | Meets international pre-painted steel coil and sheet standards |
| Chemical Composition (Base) | C ≤0.12%, Mn ≤0.60%, P ≤0.045%, S ≤0.045%, Si ≤0.50% | Low carbon steel substrate ensuring formability and coating adhesion |
| Zinc Coating Mass | Z100–Z275 (g/m²) | Hot-dip galvanized coating; Z275 = 275 g/m² total both sides per EN 10346 |
| Tensile Strength | 270–560 MPa | Varies by grade; DX51D ≥270 MPa, S280GD ≥360 MPa per EN 10346 |
| Yield Strength | 140–400 MPa | DX51D ≤300 MPa; S280GD 280–380 MPa; suitable for panel fabrication |
| Elongation | ≥22% (A80) | High elongation ensures crack-free bending and roll-forming for cleanroom panels |
| Thickness Range | 0.30–1.20 mm | Common cleanroom panel thickness: 0.40 mm, 0.50 mm, 0.60 mm |
| Width Range | 600–1,250 mm | Custom slit widths available; standard coil width 1,000 mm / 1,219 mm |
| Length / Coil | Coil: ID 508/610 mm; Sheet: 1,000–6,000 mm | Supplied as coils or cut-to-length sheets per customer requirement |
| Top Coat | Polyester (PE) / PVDF / Epoxy | PE: 15–25 µm; PVDF: 25–35 µm; Epoxy back coat 5–10 µm; anti-bacterial coating optional |
| Surface Finish | High-gloss / Matt / Anti-static / Anti-bacterial | Smooth, dust-free surface; Ra ≤0.8 µm; meets ISO Class 5–8 cleanroom requirements |
| Color Options | RAL 9002 / RAL 9003 / RAL 9016 and custom | White and light grey tones standard; custom RAL colors available with ΔE ≤1.0 |
| Application | Pharmaceutical, semiconductor, food processing, hospital cleanrooms | Wall panels, ceiling panels, partition systems, HVAC ducts in controlled environments |
| Certification | ISO 9001, SGS, CE, RoHS | Anti-bacterial coating certified per ISO 22196; fire resistance per EN 13501 |
| Packaging | Eye-to-sky coils with waterproof paper + steel strip banding; sheets in wooden pallets | Protective PE film on surface; suitable for sea and land transport |
| MOQ | 5 Metric Tons per color/specification | Mixed specifications accepted; lead time 15–25 days after order confirmation |
Clean Room Color Coated Steel Sheet - Mill Direct
Clean room color coated steel sheet is the material of choice for engineers and facility managers constructing pharmaceutical labs, semiconductor fabrication plants, hospital operating theaters, and food processing facilities that demand contamination-free environments. Engineered to meet the stringent hygiene and surface-integrity requirements of ISO Class 1–8 cleanrooms, this specialty steel combines a cold-rolled or hot-dip galvanized substrate with a multi-layer coating system that resists bacterial growth, chemical exposure, and particulate accumulation. Unlike standard prepainted steel, clean room grade panels undergo additional surface planarization to achieve a Ra roughness value typically below 0.2 µm, ensuring that microbial colonies have virtually no surface texture in which to harbor. Whether you are outfitting a new GMP-compliant production line or retrofitting an existing facility, sourcing directly from the mill means you receive consistent batch quality, traceable mill test reports, and cost-effective pricing without intermediary markups. Our production capacity exceeds 50,000 metric tons per year, enabling reliable supply for large-scale construction and fit-out projects worldwide.
What is Clean Room Color Coated Steel Sheet?
Clean room color coated steel sheet is a factory-applied, organic-coated flat steel product specifically formulated for controlled-environment construction. A continuous coil-coating line applies a primer layer followed by a functional topcoat—commonly polyester, PVDF, or epoxy resin—onto a zinc or zinc-aluminum alloy substrate. The resulting panel delivers a non-porous, easy-to-sterilize surface that meets cleanroom wall, ceiling, and partition standards while maintaining structural rigidity and fire-resistance classifications such as Class A per ASTM E84.
Clean Room Color Coated Steel Sheet Manufacturing Process
Production begins with a cold-rolled steel coil (base thickness 0.4–1.2 mm) that is hot-dip galvanized to a coating mass of Z100–Z275 g/m². The coil then enters a continuous coil-coating line where it is chemically pre-treated, primer-coated at 5–8 µm dry film thickness, cured at 230 °C peak metal temperature, and finished with a functional topcoat of 15–25 µm. Inline inspection systems verify color uniformity (ΔE ≤ 1.0 per CIE Lab), adhesion (0T bend per EN 13523-7), and pencil hardness (≥ 2H), guaranteeing every coil meets clean room specifications before dispatch.
Clean Room Color Coated Steel Sheet Technical Specifications
Standard clean room color coated steel sheet is available in the following parameters to accommodate diverse project requirements:
| Parameter | Specification |
|---|---|
| Base Steel Grade | DX51D / S220GD / S280GD (EN 10346) |
| Base Thickness | 0.40 mm – 1.20 mm (±0.02 mm tolerance) |
| Coil Width | 600 mm – 1,250 mm |
| Zinc Coating Mass | Z100 – Z275 g/m² (both sides combined) |
| Topcoat Type | Polyester / PVDF / Anti-bacterial Epoxy |
| Topcoat DFT | 15 µm – 25 µm (± 2 µm) |
| Surface Roughness (Ra) | ≤ 0.2 µm (mirror-smooth grade) |
| Tensile Strength | 270 – 560 MPa (grade-dependent) |
| Yield Strength | 220 – 420 MPa |
| Elongation (A80) | ≥ 20% |
| Gloss Level | 10 – 90 GU (60° geometry, per EN 13523-2) |
| Color Deviation | ΔE ≤ 1.0 (CIE Lab, D65 illuminant) |
| Salt Spray Resistance | ≥ 1,000 hours (ASTM B117, no blistering) |
| Antibacterial Efficacy | ≥ 99% reduction vs. S. aureus & E. coli (ISO 22196) |
| Fire Classification | Class A (ASTM E84) / B-s1,d0 (EN 13501-1) |
| Applicable Standards | EN 10169, ASTM A755, GB/T 12754 |
Custom thicknesses, proprietary colors (RAL/NCS matching), and specialized anti-static or anti-fungal topcoat formulations are available upon request with a minimum order quantity of 20 metric tons per specification.
Get a Competitive Quote for Clean Room Color Coated Steel Sheet
Partner with our mill-direct team to secure premium-grade clean room color coated steel sheet at transparent, volume-based pricing. We serve EPC contractors, cleanroom integrators, and facility owners across more than 60 countries, backed by full traceability documentation and rapid lead times of 15–25 days from order confirmation.
- 24/7 customer support available
- Free samples for quality evaluation
- Competitive pricing for bulk orders
- Professional technical consultation
Contact us today to get your free quote within 24 hours!
