Color Coated Aluminum Plate - Mill Direct Manufacturer |

Xinpeng Color Coating Co., Ltd.

Verified Custom manufacturer · 2 yrs ·

China

Customizable Rock-bottom price

$2200 1-49 ton Base price

$2103 50-99 ton 4.4% off

$2055 ≥100 ton 6.6% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 ton

Shipping total: To be negotiated

Subtotal of goods US$ 2,200.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Color Coated Aluminum Plate

Property	Parameter	Description
Product Name	Color Coated Aluminum Plate	Pre-painted aluminum sheet with polymer coating on surface
Material Grade	1100, 3003, 3105, 5052, 6061 (AA Standard)	Equivalent to EN AW-1100, EN AW-3003, EN AW-5052; common alloy series for coated applications
Standard Compliance	ASTM B209, EN 485-2, GB/T 3880, AAMA 2604/2605	Covers mechanical properties, dimensional tolerances, and coating performance requirements
Chemical Composition	Al ≥99.0% (1100); Mn 1.0–1.5% (3003); Mg 2.2–2.8%, Cr 0.15–0.35% (5052)	Alloy elements determine corrosion resistance, formability, and coating adhesion
Tensile Strength	110–290 MPa (varies by alloy and temper)	1100-H14: ≥110 MPa; 3003-H14: ≥150 MPa; 5052-H32: ≥230 MPa (per ASTM B209)
Yield Strength	85–215 MPa	3003-H14: ≥130 MPa; 5052-H32: ≥160 MPa; suitable for structural and decorative use
Elongation	4–12%	Varies by alloy and temper; 5052-H32: ≥12%; ensures formability during bending and stamping
Thickness Range	0.2–4.0 mm	Common range: 0.3–2.0 mm for roofing and cladding; custom thickness available on request
Width Range	100–2650 mm	Standard widths: 1000 mm, 1220 mm, 1500 mm; slit coil widths customizable
Length / Coil	Sheets: 500–6000 mm; Coils: OD up to 1800 mm	Cut-to-length sheets or coil supply; coil inner diameter typically 505 mm or 610 mm
Coating Type	PVDF (Polyvinylidene Fluoride), PE (Polyester), SMP (Silicon Modified Polyester)	PVDF: superior UV/weather resistance; PE: cost-effective for interior use; SMP: intermediate performance
Coating Thickness	Top coat: 20–35 μm; Primer: 5–10 μm; Back coat: 5–15 μm	PVDF top coat ≥25 μm per AAMA 2605; total dry film thickness measured per ASTM D1005
Surface Finish	Smooth, Embossed, Brushed, Matte, High Gloss	RAL/Pantone custom colors available; gloss level 10–90 GU (60° geometry per ASTM D523)
Application	Roofing, wall cladding, ACP panels, signage, automotive trim, appliances, interior decoration	Widely used in construction, transportation, and consumer electronics industries
Certification	ISO 9001, SGS, CE, RoHS, REACH	Coating performance certified per AAMA 2604/2605; RoHS compliance for heavy metal restrictions
Packaging	Wooden pallet with moisture-proof film; coils on steel mandrel with edge protectors	Export seaworthy packaging; interleaving paper between sheets to prevent surface scratching
MOQ	1 Ton (sheets); 3 Tons (coils)	Sample orders accepted; lead time 7–20 business days depending on color and specification

Color Coated Aluminum Plate - Mill Direct Manufacturer |

Color coated aluminum plate serves as one of the most versatile and visually appealing metal materials available on today's global market, combining structural reliability with an extensive palette of surface finishes. Engineered for demanding architectural, industrial, and decorative applications, these plates feature a tightly bonded polymer or PVDF coating applied directly over high-purity aluminum substrate, delivering outstanding anti-corrosion properties alongside vibrant, long-lasting color retention. From curtain wall cladding and roofing panels to signage, transportation interiors, and household appliance panels, color coated aluminum plate finds extensive application across sectors where both aesthetics and performance are non-negotiable. As a mill-direct manufacturer, we eliminate intermediary markups, giving buyers access to premium grade materials at cost-effective, factory-level pricing with full traceability from melt to finished coil or sheet.

Color coated aluminum plate manufacturer

What is Color Coated Aluminum Plate?

Color coated aluminum plate is an aluminum substrate — typically alloy series 1xxx, 3xxx, or 5xxx — that undergoes a continuous coil coating or roller coating process to bond a uniform layer of paint, PVDF, polyester, or epoxy resin onto one or both surfaces. The result is a lightweight, corrosion-resistant panel that retains precise dimensional tolerances while offering a decorative, weatherproof finish rated for 10–25 years of outdoor service life depending on coating type and environment.

Color coated aluminum plate supplier

Color Coated Aluminum Plate Manufacturing Process

Production begins with hot-rolled or cold-rolled aluminum coil that is cleaned, chemically pre-treated with a chromate or chromate-free conversion coating to maximize paint adhesion, then fed through a multi-roll coater where primer and topcoat layers are applied sequentially. Each coat is cured in a high-temperature oven at 200–260 °C to achieve cross-linked film hardness. Final inspection includes pencil hardness testing (≥ 2H), T-bend flexibility, and color consistency measured by spectrophotometer to ΔE ≤ 0.5.

Color Coated Aluminum Plate Technical Specifications

Our color coated aluminum plate is produced to the following standard parameters:

Color coated aluminum plate wholesale

Alloy grades: 1100, 3003, 3105, 5005, 5052
Temper: H14, H16, H18, H24, H26
Thickness: 0.2 mm – 4.0 mm (tolerance ±0.02 mm)
Width: 100 mm – 2,650 mm
Coating type: PVDF (70% Kynar 500), polyester (PE), SMP, HDP
Coating thickness: Primer 5–8 µm; topcoat 18–25 µm; back coat 8–12 µm
Tensile strength: 130–310 MPa depending on alloy and temper (per ASTM B209 / EN 485-2)
Gloss level: Matte (10–20 GU), semi-gloss (30–50 GU), high gloss (70–90 GU) at 60°
Salt spray resistance: ≥ 1,000 hours per ASTM B117
Color range: RAL, Pantone, or custom color matching available

All plates comply with ASTM B209, EN 485, GB/T 3880, and AAMA 2605 standards for architectural-grade coatings, ensuring full qualification for international construction and industrial projects.

Get a Competitive Quote for Color Coated Aluminum Plate

Ready to source mill-direct color coated aluminum plate at factory rates? Our dedicated team provides rapid technical consultation, precise cut-to-size options, and flexible MOQ arrangements to suit both large-scale contractors and specialized fabricators. Submit your specifications today and receive a detailed, obligation-free quotation within 24 hours.

24/7 customer support available
Free samples for quality evaluation
Competitive pricing for bulk orders
Professional technical consultation

Contact us today to get your free quote within 24 hours!

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Ankit M.

India

2025-02-02

Initial width tolerance issue on one coil — resolved satisfactorily

Ordered 7 tons of 5005-H24 at 1.0 mm, 1,250 mm width, polyester coating for rail carriage interior panels. Six of the seven coils measured within the stated ±0.02 mm thickness tolerance and width was consistent. One coil arrived approximately 4 mm under the specified width, which caused cutting waste on that batch. I raised the issue with the support team and received a partial credit within three business days along with a corrective action note for future orders. The material quality itself — hardness, coating adhesion, GB/T 3880 compliance — was not in question. Issue was handled professionally; I'd order again with this on record.

Rebecca L.

United Kingdom

2025-02-24

Competitive pricing on polyester grade, delivery slightly longer than quoted

Ordered 4 tons of 3003-H14 at 0.4 mm with semi-gloss polyester coating for appliance panel production. Price per ton was approximately 12% below what we'd been paying through a UK distributor for comparable EN 485-2 certified material. Product quality on arrival was good — coating adhesion passed our cross-cut test, and thickness tolerance was within spec. Delivery came in at 26 days versus the 20-day estimate given at order. Not a serious issue for our planning cycle, but worth factoring in. Overall a good supplier for cost-sensitive runs where a few extra days of lead time is manageable.

Tariq A.

UAE

2025-03-18

Good value for PVDF grade — minor documentation delay on first order

Sourced 10 tons of 5052-H26 at 1.5 mm with PVDF coating for a commercial building facade in Dubai. Material quality was solid — salt spray resistance verified at over 1,000 hours per ASTM B117, and the RAL 7016 color matched our architect's spec closely. Pricing was noticeably better than local distributors for equivalent AAMA 2605-grade material. The only friction was a two-day delay receiving the full MSDS and coating compliance documents, which held up our project submission briefly. Team resolved it promptly. Would order again and would rate five stars once documentation process is tightened.
